2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates
2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates
Quick Detail
S32750 stainless steel plate
|
Name |
S32750 duplex steel plate |
Brand |
AUTO KUMPO/TISCO/BAOSTEEL |
|
size |
1219mm 1500mm 1800mm or as required |
surface |
2B, BA, HL, 8K mirror, PVC coated |
|
thickness |
0.6-30mm |
Certificate |
SGS, BV |
We can produce un-standard size duplex stainless steel plate as customer required
Description
Alloy 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion.
Standards
ASTM/ASME .......... A240 - UNS S32750
EURONORM............ 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR.................... Z3 CN 25.06 Az
Applications
- Oil and gas industry equipment
- Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
- Chemical process industries, heat exchangers, vessels, and piping
- Desalination plants, high pressure RO-plant and seawater piping
- Mechanical and structural components, high strength, corrosion-resistant parts
- Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping
Specifications
Alloy 2507 is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity and a low coefficient of thermal expansion. The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion.
The impact strength is also high. Alloy 2507 is not recommended for applications which require long exposures to temperatures above 570°F because of the risk of a reduction in toughness.
Chemical Analysis
Typical values (Weight %)
| C | Cr | Ni | Mo | N | Others |
| 0.020 | 25 | 7 | 4.0 | .27 | S=0.001 |
| PREN = [Cr%] + 3.3 [Mo%] + 16 [N%] ≥ 40 | |||||
Mechanical Properties
| 0.2% Offset Yield Strength 0.2%, ksi | 80 min. |
| Ultimate Tensile Strength, ksi | 116 min. |
| 0.1% Offset Yield Strength 0.2%, ksi | 91 min. |
| Elongation in 2 inches, % | 15 min. |
| Hardness Rockwell C | 32 max. |
| Impact Energy, ft.-lbs. | 74 min. |
