Cold Rolled Brushed Stainless Steel Flat Bar , High Hardness ss flat bar 300 Series
Cold Rolled Brushed Stainless Steel Flat Bar , High Hardness ss flat bar 300 Series
- Stainless Steel Flat Bar:
- 1. Grade: 200series 300series 400series. (Standard: ASTM JIS DIN & BS)
- 2. Finish: Black & Pickled & Bright
- 3. Size: 19*3 mm-140*12 mm
- 4. Thickness: from 3mm to 12mm
- 5. Width: from 19mm to 140mm
Specifications
| Item | stainless steel flat bar |
| Material | stainless steel |
| Grade | 304, 304L, 316, 316L, 316Ti, 317, 317L, 321, 309S, 310S, 409, 410S, 420, 430, 201, 202, 904L |
| Standard | ASTM, AISI, GB, DIN, JIS, EN |
| Surface | Cold drawn orginal finish |
| Finish | cold drawn |
| Thickness | 2.5 - 50mm |
| Width | 20 - 200mm |
| Length | 1000mm-6000mm |
| Productivity | 500tons/month |
| Application | Chemical industry, shipping industry, architecture, household products, food processing and medical industry, machinery and hardware fields, etc. |
| Packing | Standard export packages, custom suffocating free. |
| Payment | Usually 30% of the amount by T/T as deposit , and the balance 70% by T/T after got the copy B/L |
| Delivery Time | within 5-30 days from confirmed order. |
| MOQ | 1 ton |
| Origin | China(Mainland) |
| Note | stainless steel sheet can be made according to the customers' requirements. |
410 stainless steel is a hardenable martensitic stainless steel alloy. Unlike austenitic grades it can be heat treated ("quench and temper") to generate high strength with good ductility. 410 alloy is required when strength, hardness and wear resistance is required with some corrosion resistance.
Due to the hardening capabilities of this steel, other properties and the resulting performance of this material are somewhat compromised. The alloy can only effectively be used in mildly corrosive environments. The operating temperature range is limited a) a loss of strength by over tempering at elevated temperatures and b) a loss of ductility at sub-zero temperatures.
Type 410 is officially a stainless steel but characteristically the material is actually a compromise of high carbon steel alloy (which promotes wear resistance) with chromium stainless steel (which promotes corrosion resistance).
Chemical Composition
| UNS No | Grade | C | Si | Mn | P | S | Cr | Mo | Ni | N | Other |
| S41000 | 410 | 0.08/0.15 | 1.00 | 1.50 | 0.040 | 0.030 | 11.5/13.5 | –– | 0.75 | –– | –– |
Mechanical Properties
| UNS No | Grade | Proof Stress 0.2% (MPa) |
Tensile Strength (MPa) |
Elongation A5 (%) |
Hardness (Max) | |
| HB | HRB | |||||
| S41000 | 410 | 205 | 450 | 20 | 217 | 96 |
Our Stainless Steel Flat Bar We can Provide
| SEPCIFICATIONS | ALLOWABLE DEVIATION |
| 25 X 3~15MM (1" X 1/8"~3/5") | 1.WIDTH<50mm,THICKNESS<20mm, THICKNESS DEVITION ±0.4mm. |
| 30 X 3~16MM (1-1/5" X 1/8"~16/25") | |
| 35 X 3~16MM (1-2/5" X 1/8"~16/25") | |
| 40 X 3~16MM (1-3/5"X1/8"~16/25") | |
| 45 X 4~16MM (1-4/5" X 4/25"~16/25") | |
| 50 X 4~16MM (2" X 4/25"~16/25") | |
| 60 X 4~16MM (2-2/5" X4/25"~16/25") | |
| 65 X 4~16MM (2-3/5" X 4/25"~16/25") | |
| 70 X 5~16MM (2-4/5" X 4/25"~16/25") | 1).WIDHT<50mm,THICKNESS DEVIATION ± 0.8mm |
| 75 X 5~16MM (3" X 1/5"~16/25") | |
| 80 X 5~16MM (3-1/5" x 1/5"~16/25") | 2).50mm<WIDTH<75mm,WIDTH DEVIATION ± 1.2mm |
| 90 X 5~16MM (3-1/2" X1/5"~16/25") | |
| 100 X 5~18MM (4" X 1/5"~7/10") | 3).75mm<WIDTH<150mm,WIDTH DEVIATION ±1.5mm. |
| 120 X 8/20MM (4-7/10"~3/10"&4/5") | |
| (130~300) X (10~20)MM (5"~12") x(2/5"~4/5") |
Application
Food processing equipment, particularly in beer brewing, milk processing & wine making.
Kitchen benches, sinks, troughs, equipment and appliances
Architectural panelling, railings & trim
Chemical containers, including for transport
Heat Exchangers
Woven or welded screens for mining, quarrying & water filtration
Threaded fasteners
Springs
our service
A) Small MOQ of Stainless Steel Flat Bar
B) Large supply ability of Stainless Steel Flat Bar
C) Can accept any complex inquiry of Stainless Steel Flat Bar
D) Stock available of Stainless Steel Flat Bar
E) Strong processing and warehousing service for Stainless Steel Flat Bar
F) Strict quality control for Stainless Steel Flat Bar
G) Professional negotiation for Stainless Steel Flat Bar
