Plating & Surface Finishing Ultrasonic Bath Cleaner 3600w Ultrasonic Washer
Plating & Surface Finishing Ultrasonic Bath Cleaner 3600w Ultrasonic Washer
Skymen ultrasonic cleaners are used in many surface finishing and plating applications for companies across a diverse mix of industries. And tank size of the machine can be customized!
If any problem, welcome to ask sales6(at)skymen.cc.
Specifications:
With digital timer and heater;
Oil filtration system is optional to recycle the solvent and prevent the second pollution;
Tank size can be customized according to the cleaning objectives
Applications:
Skymen Dual frequency ultrasonic cleaner can be use for car parts washing, engine block degrease,
radiator
clean, also can clean electronic parts. No damage to object surface and improve cleaning efficiency.
Description:
- Adjustable ultrasonic power
- Original BLT type transducer
- SUS304/316L tank
- Adaptable for continuous operation
- Adjustable thermo controller
- Adjustable ultrasonic power
- With separate control ultrasonic electronic generator
- Sweep mode control available
- Digital timer control
- Boost mode& oil skimmer upon client’s requirement
- Pressure pump and filter system
- With pneumatic lift to up and down goods.
Product Description
Model: Skymen™ | JTS-1012 | JTS-1018 | JTS-1024 | JTS-1030 | JTS-1036 | JTS-1072 | |||
TANK'S WORKING DIMENSION (mm) | L1 | 355 | 406 | 500 | 500 | 500 | 1110 | ||
W1 | 305 | 305 | 355 | 406 | 460 | 600 | |||
H1 | 355 | 460 | 500 | 500 | 550 | 600 | |||
OVERALL DIMENSION (mm) | L2 | 535 | 586 | 680 | 710 | 710 | 1320 | ||
W2 | 485 | 485 | 535 | 586 | 640 | 780 | |||
H2 | 750 | 680 | 720 | 720 | 770 | 820 | |||
TANK'S TOTAL CAPACITY | 38L | 56L | 88L | 101L | 126L | 369L | |||
TANK'S MATERIAL | SUS304 / SUS316L | ||||||||
IN-TANK SURFACE FINISHING | Hard-Cr Plating Treatment ( 20+ microns ) | ||||||||
HOUSING'S MATERIAL | Stainless steel | ||||||||
ULTRASONIC FREQUENCY* | 28kHz / 40kHz | ||||||||
ULTRASONIC TRANSDUCER | 12 | 18 | 24 | 30 | 36 | 72 | |||
ULTRASONIC OUTPUT POWER (MAX.) | 600W | 900W | 1200W | 1500W | 1800W | 3600W | |||
ELECTRONIC GENERATOR | KG600 | KG900 | KG1200 | KG1500 | KG1800 | KG3600 | |||
Build-in | Separate | ||||||||
HEATER'S (HOT PLATE) POWER | 1.5kW | 3kW | 4.5kW | 9KW | |||||
Package
Packing , loading, delivery time | |
Packing unit | 1set/wooden case |
Packing method | Export wooden case |
Loading port | Shenzhen |
Delivery time | About 15 working days |
Minimum Order Quantity | 1set |
Transport method | By express company / air / sea |
Competitive Advantage:
- Material : SUS304/316L with 2mm thickness
- 15 years experience engineer will design the machine for you
- Filtration System: for heavy duty oil removing, cycle cleaning solvent, prevent second polution and
- better cleaning effects.
- PCB Board: manufactured by Skymen factory, more stable
