Sliding Aluminium Roller Track Wooden Acoustic Material Folding Partition Wall

Specification:

Folding partition wall offers unique custom made Acoustic Movable Wall Partitions which facilitates in managing.Your space to its maximum capacity. Our movable partition wall system constitutes of panels

Suspended individually from the rail fixed to the top of the roof. The classroom movable wall partition has retractable top and bottom seals which interlocks each panel to its position. If required, hinged pass doors shall be provided through the Acoustic Movable Wall Partition where access is required.

Feature:

Folding partition wall has top hung with no floor track.

Scissor-jack operating mechanism.

Available with virtually any surface finish.

Ideal for conference centres, hotels, offices & schools.

Angled, glazed, corner or junction panels for maximum flexibility.

Single or double point suspension for versatile stacking options.

Panels with hinged pass door, single or double leaf inset pass door panels for access through.

Sliding aluminium profile details:

Folding partition wall seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.

For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.

For panel up to 225 kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.

Technical information:
