CE&ISO Equal Angle Bar Steel Profile Roll Forming Machine 0.8-1.5mm Galvanized Steel Coil
CE&ISO Equal Angle Bar Steel Profile Roll Forming Machine 0.8-1.5mm Galvanized Steel Coil
Equal Angle Making MachineTechnical Parameter
| Items | Specifications |
Material of coil | Material Thickness | 0.8-1.5 mm galvanized |
De-coiler | Weight | 3 ton manual |
Forming system | Rolling Speed | 10-12 m/min |
Roller Stations | About 13 stations forming | |
Roller Material | Gcr15 Steel with quenching | |
Shaft Material | 45# Steel Diameter 75mm shaft | |
Maim Motor Power | 5.5 kw | |
Hydraulic cutting Power | 3 kw | |
Cutting | Material Of Cutting | CR12 with quench treatment |
Hardness | HRC58-62 | |
Tolerance | +-1.5mm | |
Cutting blade | 1 set of cutting blade | |
Electrical control system | Electric Source | 220V, 60HZ,3 phase |
Control System | PLC with touch screen Japanese Panasonic and Yaskawa Brand | |
| Weight | About 3.5 tons |
| Way Of Drive | 1 inch single chain |
| Size of machine | Length 6500mm* Width 600mm* Height 800m |
Main Components
Machine list | 3 ton passive de-coiler | 1 set |
Feeding with guide | 1 set | |
Main roll forming machine | 1 set | |
PLC Control box | 1 unit | |
Hydraulic station | 1 unit | |
Stop cutting device | 1 unit | |
Safety cover | 1 unit | |
Out table | 2 units |
Working Flow of Roll Forming Machine
feedingwithguide—Rollforming——Cutting—Products collecting
Standard Profile Drawing of product
Photo Gallery
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
