High Performance Consumer Electronics White Acrylic Adhesive 0.8W/MK Thermal Adhesive Tape With Double-Sided Adhesive
High Performance Consumer Electronics White Acrylic Adhesive 0.8W/MK Thermal Adhesive Tape With Double-Sided Adhesive
The TIA®806 Series is filled with good thermal conductivity ceramic particles, featuring excellent thermal conductivity, strong adhesion and electrical insulation. It is suitable for bonding and fixing electronic components to heat sinks or housings, such as LED modules, power devices, communication equipment and other scenarios. The product is solvent-free, pollution-free, easy to construct, and can replace the traditional combination scheme of screw fixation and thermal conductive grease.
Features
> Thermal Conductivity: 0.8 W/mK
> High bonding strength
> Good thermal conductivity efficiency
> Easy to apply and can be die-cut into custom sizes
> Stable operation over a wide temperature range
Applications
> LED module
> Power device
> Consumer electronics
> Communication equipment
| Typical Properties of TIA®800 Series | ||||||||
| Product Name | TIA®802 | TIA®804 | TIA®806 | TIA®808 | TIA®810 | TIA®812 | TIA®815 | Test Method |
| Color | White | Visual | ||||||
| Adhesive Type | Acrylic Adhesive | ****** | ||||||
| Continuous Use Temp | -40℃ to 125℃ | ****** | ||||||
| Thickness | 0.002" 0.05mm | 0.004" 0.10mm | 0.006" 0.15mm | 0.008" 0.20mm | 0.010" 0.25mm | 0.012" 0.30mm | 0.015" 0.38mm | ASTM D374 |
| Voltage Breakdown | ≥600 | ≥1200 | ≥1800 | ≥2500 | ≥2700 | ≥3000 | ≥4000 | ASTM D149 |
| Thermal Conductivity | 0.8 W/mK | ASTM D5470 | ||||||
| 180° Peel Adhesion (gf/inch) Steel, Immediate | ≥ 1200 | ASTM D3330 | ||||||
| 180° Peel Adhesionk (gf/inch) Steel, 24 hrs | ≥ 1400 | ASTM D3330 | ||||||
| Holding Power (H/inch) @25℃ | ≥ 48 Hours | ASTM D3654 | ||||||
| Holding Power (H/inch) @80℃ | ≥ 48 Hours | ASTM D3654 | ||||||
Standard Thickness:
Standard Size: 16" x 100" (406 mm x 30.48 M)
Reinforcing Carrier: TIA®800 Series rolls can be reinforced with glass fiber.
The TIA® series can be provided with die-cutting into vaious shapes, For different thicknesses or more information about
thermally conductive materials, please contact our company.
