R404a Refrigerant 10 Ton Ice Cube Machine For Restaurant , Supermarket
10 tons cheap factory use energy saving stainless steel large capacity ice cube machine
10 tons cheap factory use energy saving stainless steel large capacity ice cube machine
Application:
Cube ice machines are widely used in hotels, restaurants, bars, fastfood shops, supermarkets and cold drink shops,et. Icesource ice machine are highly efficient, energy saving,safe and environmentally friendly and quickly becoming the most popupar choice for client around the world.
10 tons per day Commercial Ice Cube Making Machine Parameters
|
Working Conditions |
Refrigerant | R507/ R404a |
| Cooling way | Water cooling / Air cooling | |
| Power supply | 380v/50Hz/3phase , 380v/60Hz/3phase , 220v/50Hz/3phase, 220v/60Hz/3phase |
|
| Ambient temp. | +32 ℃ | |
| Supply water temp | +20 ℃ | |
| Evaporating temp. | -12 ℃ | |
| Condenser temp. | +40 ℃ | |
| Relative humidity | 85 % | |
| Noise | 55dB | |
|
Compressor |
Brand Name | (Germany) |
| Product Model | 6HE-28 | |
| Power | 19.3kw *2 | |
| Refrigerating Capacity | 48.5kw *2 | |
|
Cooling Tower |
Brand Name | CBFI |
| Size | Φ2100*H2080 mm | |
| Power of Cooling Water Pump | 4kw | |
| Power of Cooling Fan | 1.5kw | |
| Ice making water Circulating pump | Brand Name | Nanfang |
| Power | 4kw | |
|
Ice Outlet Motor |
Brand Name | Nord |
| Power | 1.1kw | |
| Delivery time | 62 days after the receipt of deposit | |
10 tons per day Cheap Ice Cube Machine Supporting Equipment
1. Cold room :storage ice and keep the ice in high quality.
2. RO water treatment equipment :Purify the water , make cube ice more clean and crystal.
3. Sealer : sealing the ice bag
4. Digital scale:scale the bag ice
Machine outlook:
Stainless steel material with good quality and nice look.
Feature of 10 Tons Large Capacity Ice Cube Machine:
- Size of ice: 22*22*22, 29*29*22
- Output: 3 tons per 24 hours
- Power Consumption: 85 kw.h for each ton
- Working condition: environmental temperature: 32℃, water supply temperature: 20℃
Packing & Delivery:
- Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water fittings.
- Machine come into use, customer only need prepare power for the machine.
- All required components for installing the machine will be provided.
