40G Data Center MTP Trunk Patch Cable / MPO To LC Duplex Uniboot Harness Cable 8 12 24 Core PVC LSZH Cover
MPO series offers the solution from trunk cables to extended trunk cables, to hybrid trunk cables, to cassette modules, to MPO adapter panels, to direct patch panels, to patch panels in both MPO classification of G class(normal class) and L class(super low loss).
We provide a full line of high performance MTP /MPO fiber cable assembly, they are designed for high-density backplane and Printed Circuit Board (PCB) applications in data and telecommunication systems. With the based on single ferrule MT technology, our MTP /MPO fiber cable assembly can be up to single ferrule with 24 fiber cores connections.
MT Series Solution includes MTP /MPO Patch Cords, MTP /MPO Harness Cables, and MTP /MPO Trunk Cables. With the sourcing MPO connectors from Japan and MTP connectors from US Conec, production with our advanced equipments under our experienced and skilled technique, all our MTP /MPO fiber cable assembly products are designed to meet or exceed EIA/TIA, IEC and Telcordia standards for performance and reliability. The MTP /MPO cassettes and patch panels are available as well.
Kocent Optec Limited is one of leading company in developing and manufacturing advanced fiber optic products, mainly offer CPRI waterproof jumper, MPO/MTP patch cord, standard fiber optic patch cord, fast connector, PLC Splitter, fiber optic box, and cable.
We provide OEM/ODM service with all type length of MPO/MTP patch cable.
Our MPO/MTP patch cable are available in Single mode and Multimode ( OM1, OM2, OM3, OM4, and OM5).
Connector can be MPO/MTP and other type of connector such as LC, FC, ST, SC, E2000, MU, DIN, MTRJ, ...
- Data center systems cabling
- 100% factory tested
- Available in OM1, OM3, OM4 and SM OS2 fiber types
- Available in 12, 24, 36, 48, 72, 96, 144, or custom fiber counts
- All patch cords are pre-labeled and individually bagged
- Custom configurations available upon request
- RoHS compliant – Riser, Plenum, and LSZH rated cables available
- CATV,
- Metro,
- Test Equipment,
- Premise installations,
- Active device termination,
- Telecommunication networks,
- Local Area Networks(LANs),
- Data Processing networks,
- Wide Area Networks(WANs),
- FTTx (FTTH, FTTO, FTTB, FTTA, ...)
| Type | Single Mode | Single Mode | Multi Mode | |||
| (APC Polish) | (UPC Polish) | (PC Polish) | ||||
| Fiber Count | 8,12,24 etc. | 8,12,24 etc. | 8,12,24 etc. | |||
| Fiber Type | G652D,G657A1 etc. | G652D,G657A1 etc. | OM1,OM2,OM3 etc. | |||
| Maximum Insertion Loss | Elite | Standard | Elite | Standard | Elite | Standard |
| Low Loss | Low Loss | Low Loss | ||||
| ≤0.35 dB | ≤0.75dB | ≤0.35 dB | ≤0.75dB | ≤0.35 dB | ≤0.60dB | |
| Return Loss | ≥60 dB | ≥60 dB | NA | |||
| Durability | ≥500 times | ≥500 times | ≥500 times | |||
| Operating Temperature | -40℃ ~ +80℃ | -40℃ ~ +80℃ | -40℃ ~ +80℃ | |||
| Test Wavelength | 1310nm | 1310nm | 1310nm | |||
If you want to show your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.
According to Stardard Export Packing.
Carton box, wooden box, wooden pallet.
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
