H07BZ5 - F 5C × 6mm2 + 2C × 0.75mm2 + W EV Charing Cable

H07BZ5-F 5C×6mm2+2C×0.75mm2+W

Product Description

A:5C×:6mm2 B:2C×0.75mm2 Jacket
Conductor Bare copper stranded
Cross section 6mm2   0.75mm2 Tensile strength ≥20MPa
Construction 136/0.15mm+Tinsel+ Kevlar 28/0.15mm+Tinsel+ Kevlar
Elongation ≥300%
Strand Dia.(Ref.) 3.40mm   1.3mm
Aged condition 110±1ºC×168h
Insulation EVI-2 Percent of original tensile strength ±30%
Nom.Thickness 0.70mm  0.41mm
Min.Thickness 0.53mm   0.33mm
Insulation Dia. 4.80±0.20mm   2.20±0.10mm
Insulation colour
A.brown,blue,yellow/green,gray,black B.red
Filler PP rope
Assembly  5C×6mm2+2C×0.75mm2+W
Jacket EVM-1
Reference standard:EN50620-2017
Nom.Thickness 1.4mm
Min.Thickness 1.09mm
Outer Dia. 16.60±0.35mm
Colour per request
