19-w-4 Platform Steel Grating Hot Dipped Galvanized Mild Steel Bar Grating
1. Galvanized steel grating Features:
1) Bearing bar specification: 20 x 3 to 100 x 6
2) Bearing bar pitch: 12.5, 15, 30, 40, 60mm etc, also be according to client's requirement and 30, 40, 60mm are recommended
3) Cross bar pitch: 38, 50, 76, 100mm, also be according to client's requirement and 50, 100mm are recommended
4) Material: Mild steel or stainless steel
5) Surface treatment: Untreated, painting or hot DIP galvanizing
6) Steel Grating Standards:
2. Service
- 24 hours on-line service
- Excellent service for pre-sale,on-sale and after-sale
- Expert at our products
- Competitive price with superior higher quality products
- Factory with its own workshop
- Strict test before its delivery
19-w-4 Platform Steel Grating Hot Dipped Galvanized Mild Steel
3. Advantages
-light weight-easy to install and clean-nodem
-nice appearance-high strength-ventilation and light can pass through
-material saving-slip-resistant and safe
-heavy loading and durable
Service
- 24 hours on-line service
- Excellent service for pre-sale,on-sale and after-sale
- Expert at our products
- Competitive price with superior higher quality products
- Factory with its own workshop
- Strict test before its delivery
4. Steel Grating Application :
steel bar grating is mainly used in chemical industry, food processing, hydro processing and other industries as listed
- Power plant
- Chemical plant
- Oil Refinery
- Steel plant
- Machinery plant
- Paper-making factory
- Cement plant
- Civil engineering
- Wastewater treatment
- Pharmacy industry
- Food processing
| No. | Item | Description |
| 1 | Bearing Bar |
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10,100x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc US standard: 1'x3/16', 1 1/4'x3/16', 1 1/2'x3/16', 1'x1/4', 1 1/4'x1/4', 1 1/2'x1/4', 1'x1/8', 1 1/4'x1/8', 1 1/2'x1/8' etc. |
| 2 | Bearing Bar Pitch |
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc. |
| 3 | Twisted Cross Bar Pitch | 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2' & 4' etc |
| 4 | Material Grade |
ASTM A36, A1011, A569, Q235, S275JR, SS304, Mild steel & Low carbon steel, etc |
| 5 | Surface Treatment | Black, self colour, hot dip galvanized, painted, spray coating |
| 6 | Grating Style | Plain / Smooth, Serrated /teeth, I bar, serrated I bar |
|
7
|
Standard |
China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987, Australia: AS1657-1985, Japan:JIS |
| 8 | Application |
-Rotation ways, channels, and platforms for pump rooms and engine rooms in various ships; -Flooring in various bridges such as railway bridge sidewalks, over-bridges across the street; -Platforms for oil extraction sites, car washing sites and air towers; -Fencings for car-parks, buildings and roads; drainage trench covers and drainage pit covers for high strength . |
Gnee Is one of the leading manufacturers specializing in producing press-welded steel grating in China.
Founded in 2008, covering an area of 25000 square meters and with workshop area of 18000 square meters, Gnee has advanced equipments, full-fledged technology as well as rich manufacture and management experience in press-welded steel grating area over 10 years. GNee is among the few leading manufacturers who have the entire production process from bearing bar to galvanized steel grating.
