3mm Dye Industry Double Diaphragm Pump For Waste Oil Less Than 68db
3mm Dye Industry Double Diaphragm Pump For Waste Oil Less Than 68db
Air diaphragm pump & Barrel Pump
(also know as a Membrane pump, air operated double diaphragm pump(AOOD)or pneumatic diaphragm pump)that uses a combination of the reciprocating action of a rubber,thermoplastic or diaphragm and suitable valves either side of the diaphragm (check valve,butterfly valves,flap valves,or any other form of shut-off valves) to pump a fluid.
The diaphragm pump offers high volume delivery even at low air pressure and a b road range of material compatibility options available.Refer to the model and option chart.The pump is provided with the modularized air motor and fluid section.
The air operated diaphragm pump alternately generates the intake fluid pressure and positive fluid pressure in the fluid chamber by using the pressure difference in the air chamber. The ball valve can ensure the forward flow of fluid.
Pump cycling will begin as air pressure is applied and it will continue to pump and keep up with the demand. It will build and maintain line pres -sure and will stop cycling once maximum line pressure is reached (dis -pensing device closed) and will resume pumping as needed.
| Item | Description | Unit | Reference Figure |
| 1 | Maximum air inlet pressure | Mpa | 0.6 |
| 2 | Maximum flow rate | 1/Min | 46 |
| 3 | Maximum lift | M | 40 |
| 4 | Maximum outlet pressure | Mpa | 0.6 |
| 5 | Maximum particle size | mm | 3 |
| 6 | Weight | kg | 1.8 |
| 7 | Noise level | db | ＜68 |
| 8 | Max dry suction | m | 4.2 |
Feature of Air Diaphragm Pump
1. Non leakage
2. Good self priming performance
3. Convey all kinds of medium
4. Material:Cast steel,Alu,SS,PP
Application area:
Chemical Industry;
Coating Industry;
Painting Industry;
Dye Industry;
Pigment and Textile Chemical Industry;
Food Industry;
Water treatment Industry;
Petroleum Industry;
Environmental protection Industry;
Pharmaceutical Industry
FAQ
1. Q: Are you a factory or trading company?
A: We are manufacturer in shanghai.
2. Q: What're your payments ?
A: T/T,Western Union,L/C etc.
3. Q: What about the package ?
A: Standard export plywood case or carton.
4. Q: How long is the warranty ?
A: We have 1 year warranty, except wearable parts.
5. Q: The use of products have?
A: The pump can suck the peanut, pickles, tomato slurry, red sausage, chocolate, hops and syrup etc.
The pump can suck the paint, pigment, glue and adhesive etc.
The pump can suck various glazed slurries of tile, porcelain, brick and chinaware etc.
