3Ton 30M Hydraulic Telescopic Boom Crane Radius Pedestal Floating Barge Deck Marine
Price:
negotiation
MOQ:
1
Delivery Time:
60 days
Brand:
OUCO
Product Description
High Quality New Marine Deck Telescopic Jib Cranes Machine Provided From China Factory
Product Description
The telescopic series of cranes offer a diverse product line for application in the Luxury Yacht, Oceanographic, Workboat, Oilfield, Coast Guard or Military industries. These cranes can also be further customized for use in these most demanding of work environments.
The 3T30M Telescopic boom crane is the first marine crane OUCO has shipped to South America. This crane is available from 3–30 meters of crane boom, which have long range of usage.
Main Features And Advantages
Easy maintenance at all situation;
Self contained unit with integrated hydraulic power pack.
Fail-safe brakes on all movements.
Fully enclosed and equipped operator cabin with air condition.
The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.
Technology from Germany.
Base on many year's design and fabrication experience of crane and other similar equipment.
Suitable for all kinds of ships and low power consumption and high efficiency.
Fail-safe brakes on all movements.
Fully enclosed and equipped operator cabin with air condition.
The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.
Technology from Germany.
Base on many year's design and fabrication experience of crane and other similar equipment.
Suitable for all kinds of ships and low power consumption and high efficiency.
Welded and high strength box boom for easy maintenance.
With Many safety protection devices---hook up limiter and overload limiter, emergency stop button.
Product information
| SWL | 3T 30M |
| Max.working radius | 30M |
| Min.working radius | 3M |
| Hoisting height | 35M |
| Hoisting speed | 0-15m/min |
| Slewing speed | 0.6r/min |
| Luffing time | 90S |
| Working condition | heel: ≤ 5 ° trim:≤2° |
| Motor power | Y160L-4-H 90kw |
| Speed | 1780 rpm |
| Power resourse | AC 440V/60HZ/3P |
| Protect class | IP44 |
| Insurance class | F |
| Working type | S1 |
Production process
Company Information
Company Information
OUCO Industry, was established in February 1984, covers an area of 48,000 square meters, construction area is 35,000 square meters. OUCO headquartered in crane hometown of Jiangsu Province where representing most advanced machinery manufacturing level in China. OUCO has more than 150 employees, 20 were technical staff. Among that has five senior titles, 10 mid-level titles, and a total of 50 welder (who has got CCS, ABS and other main institutions’ certification). It also has professional organization certificated flaw detection staff, the quality system audit staff, and inspection personnel, etc.
FAQ
1.Q:What's working radius of your crane?
A: From 1m to 100m, we can design and make according to your requirement.
2.Q: Which crane type should I choose?
A:We have foldable boom, knuckle boom, telescopic boom, stiff boom, etc.
3. Q:Can this crane be explosion proof?
A:Sure, we can equip any extra function based on your requirement.
4. Q:Does your crane have safety devices?
A:Of course, we have all cut off limits and alarms for safety reasons.
5. Q:How can I install the crane to my vessel?
A:We can send our service engineers to the vessel site for guiding or ship the crane in whole piece.
6. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
