Black Color Coaxial Cable TV Set Top Box HD 1080P DVB-C Set Top Box
Coaxial Cable DVB-C TV Set Top Box
Modle NO:DCR-3321
The Descriptions of DVB-C TV Set Top Box:
Support MPEG1-Audio,MPEG2-audio,LayerI/II,stereo audio decoding ,Dolby(optional).
Support HD/SD digital signal
Support auto search , manual search , full frequency search .
Support EPG
Support OSD
Support online software upgrade and local upgrade.
HDMI output
Support 1080p,720p,576p,576i
Technical Index of DVB-C TV Set Top Box:
| Items | Parameters of DVB-C Set Top Box |
| Frequency | 47-862MHz |
| Channel Standard | DVB-C EN300 429 |
| Modulate type | 16/32/64/128/256QAM |
| Symbol Rate | 3.6-6.952MS/s |
| Video Decode | MPEG-2MP@ML/MPEG4SP@ASP/Divx/AVS/AVX+/Real/VC-1/H.264/H.265 |
| Video output | 1080P50(60)/1080i/720p/576p |
| Audio encode | MPEG-1(layer1&2/MPEG-2/AAC/AC3/RA/WMA/Dolby digital plus |
| Audio mode | L/R/STO |
| CPU process speed | Main frequency@700MHz |
| FLASH memory | 8MB |
| RAM memory | 128MB |
| Display | POW/CLOCK LED indicator |
| Panel Button | Standby/channel |
| RF input | British F type |
| Audio output | PJ-322(L/R/CVBS) |
| HDMI output | HDMI1.3b(HDCP) |
| USB | USB2.0 |
| IR loop out | Mini USB-RS232 |
| Input voltage | DC:12V/0.8A |
| Power consumption | 10W(max) |
| Dimension | 112*112*24mm |
|
Picture of DVB-c Set Top Box: |
|
Key Features of DVB-C TV Set Top Box:
*Completely meet the standard of DVB-C/MPEG/H.264/H.265/AVS/AVS+
*Support multi star QAM modulation.(16/32/64/128/256QAM)
*Support multi mainstream CA conditional receive system.
*Support EPG and program reservation management and EPG advertisement business
*Support mainstream middle ware ,bidirectional browser and information customization service.
*Support PVR reservation and real time recording and encoder application
*Built in EOC gateway module,support multi business VLAN and all business management
*Support time shift and watch back for external storage device
*Built in player,support USB local video/music/picture player
*Support loader air upgrading manual,automatic and USB etc.Its able to upgrade to latest version in time.
Physical interface of TV Set Top Box:
RF output: IEC male
Video output: 1 x CVBS
Audio output: 1 x RCA stereo
IR interface: 1
DC input: 12V/1A
