Bentonite Waterproof Clay Liner 5.8m X 50m Per Roll For Reinforcement

Price Negotiable
Price: Negotiable
MOQ: 1 Ton
Delivery Time: 5-7days
Brand: huatao
Product Description





Bentonite Waterproof Clay Liner 5.8m X 50m Per Roll For Reinforcement



Bentonite Waterproof Clay Liner Specification



Name



Bentonite Waterproof Clay Liner ( GCL)



GSM of GCL



3500g- 6000g



Recommend size



5.8m x 30m per roll or 5.8m x 50m per roll



Structure of GCL - 5 Layer



First Layer - Woven Geotextile (120GSM with PP Material)


Second Layer - Nonwoven Geotextile (220GSM With PET or PP Material)


Third Layer - Clay


Fourth Layer - Nonwoven Geotextile (220GSM With PET or PP)



Five Layer - HDPE Geomembrane (0.2mm thickness white or black color)



Loading of GCL



20ft container, 40ft container



Samples



would be supply as free





Sodium bentonite granule consists of natural clay inorganic mineral materials processed with high expansion and high water absorption capacity, low permeability when wet performance, mainly for waterproofing.



Bentonite Waterproof Clay Liner  Property



1)Swell when meet water

2)Long time waterproofing and friendly to environment

3)Separation, reinforcement, protection, filtration and easy for construction





Production standard

JC/T 193-2006



Bentonite Waterproof Clay Liner  Application



1. Applies to new civil engineering planted roof garden, basement, roof and other water projects; Water projects

2. subway, railway, municipal roads, light industry, petroleum and metallurgical industries;

3. earthwork repair and reinforcement of anti-seepage project;

4. Desert governance, environmental reform, landfill, artificial lakes, man-made landscape soil waterproof blanket a large area;

5. water conservancy projects was even better, in a large area of water seepage construction of buildings, small Reservoir, dam, irrigation canals, reservoirs ponds, etc. can have a wide range of applications
