Automatic Laying Hens 54 Birds Poultry Battery Chicken Cage For Chicken Farm
Automatic Laying Hens Poultry Battery Chickens Cages For Egg Layer Chicken Farm
Laying hens poultry battery chicken cages are widely running in egg layer chicken farms, according to the farm scale, both A and H type can be chosen.
Description Of Poultry Battery Chicken Cages For Egg Layer Chicken Farm
| Layer Chicken Cage System |
1. Size: 650x625x500mm, 450x500x410mm, 450x600x430mm. 2. Material: Hot dip galvanizing, Q235 national bridge steel, which ensures the cage meshes give enough elasticity to the layer birds and make the chicken feel good for laying eggs. 3. Feed trough: made of PVC ones(100% new material) or 1.0-1.2mm 4. Can be designed into 3, 4, 5, 6, 8, 9, 10 Tiers; 5. Capacity:54-384 birds/set |
| Automatic Feeding System |
1. The traveling hopper(feeding carts) type, gantry feeding type and chain feeding systems are available. 2. The feeding cart connected with the silo by the transverse feeding auger is more populate here. In this system, feed is distributed automatically to the feed carts from the feed silos by the spiral augers located in a pipe with 90-150mm diameter ； The augers and chain material is made in South Africa. Traction Device :Power of motor:0.75kw,tow rope: pp rope with 14mm,speed:8.67m/minute. 3. Track of Trolley:Hot-dip galvanized steel with 48mm*2.75mm. 4. Head and end frame:Hot-dip galvanized steel with 40mm*60mm*3mm. 5. Silos&upoading feeding device are included or can be optional. |
| Automatic Water Drinking Lines |
1. Nipple Drinkers: 360 degree 2. Water Pipes: 2.5mm PVC round tubes or square pipes are available 3. Water Pressure regulator 4. Filter 5. Medical pump imported from France
|
| Automatic Egg Collecting System |
1. Hot-dip galvanized 1.5mm side plate,speed 4m/min. 2. Egg guider:Hot-dip galvanized with thickness 1mm,configuration with stretching device. 3. Egg belt:100mm width 4. Crosswise egg conveyor |
| Automatic Manure Remove Machine |
1. Belt type manure cleaning machine:Hot-dip galvanized 2. Manure cleaning belt:Material is PP, Thickness is 1.2mm.Width is 1.2m/ 1.25m. 3. Bracket for manure cleaning belt:hot-dip galvanized steel, 1.5mm thickness. 4. Transverse manure conveying
|
| Environmental Controller | Fans, cooling pad, air inlets, intelligent controller |
Laying Hens Poultry Battery Chicken Cages Feature
| No. | Egg Layer Chicken Farm Poultry Battery Cages Feature |
| 1 | Comfortable and safe feeding environment |
| 2 | Higher egg production rate |
| 3 | Eggs damaging rate as low as 0.3% |
| 4 | Mortality in the whole raising process is only 5% |
| 5 | Reasonable area per bird |
Laying Hens Poultry Battery Cages Merits:
| 1 | High land utilization |
|
| 2 |
Comfortable and safe feeding environment
|
Timely and effective manure remove methods.
|
| 3 | Efficiently Chicken Raising Equipment |
|
Our Service
| 1 | Get free quote 24 hours design | Professional design team to provide you with design solutions with 24 hours. |
| 2 | 15-30 days production | Produces layer egg chicken battery cage only 15-30 days |
| 3 | 45 Days installation | Our engineers did the work include construction and installation,site testing and instructing. |
| 4 | 365 Days first-class service |
We are always happy to support you with technical,farming and emergencies questions.
|
