Communication Power Supply Automotive Blade Fuses DC32V 2A Gray

Price Negotiable

Price: Negotiable

MOQ: 100pcs

Delivery Time: 5-8 days

Brand: Dissmann

Product Description

Basic information of the DFN-A Series Automotive Blade Fuses

Medium plug-in automobile fuse, size and performance conform to UL248

Rated voltage: 32VDC

Rated current: 1~40A

Breaking capacity: DC1000A

Conform to EU and China RoHS directives

The executive standard is UL248, UL certification number: E343461

DFN-A Series Automotive Blade Fuses are automotive plug-in fuses with small size, low power consumption and high breaking capacity. It is applicable to the internal branch protection of automobile electrical appliances, UPS, communication power supply short circuit and backup protection. This product has good vibration resistance and flame retardancy.

1. Dimension of the DC32V 2A Gray Automotive Blade Fuse (mm)

2.Product model of the DC32V 1A-40A Automotive Blade Fuse

Model	Product code	Rated current A	I²t (A²Sec)	Voltage drop mV	Pigment
DFN-A	DFN-A-1	1	0.4	174	(Black)
	DFN-A-2	2	1.5	140	(Gray)
	DFN-A-3	3	6.3	137	(Violet)
	DFN-A-4	4	13	135	(Pink)
	DFN-A-5	5	25	125	(Tan)
	DFN-A-7.5	7.5	56	115	(Brown)
	DFN-A-10	10	110	110	(Red)
	DFN-A-15	15	295	102	(Blue)
	DFN-A-20	20	480	96	(Yellow)
	DFN-A-25	25	1000	90	(Clear)
	DFN-A-30	30	1460	86	(Green)
	DFN-A-35	35	2205	88	(Dark green)
	DFN-A-40	40	3200	95	(Orange)
