Low Vibration Jaw Rock Crusher Large Throughput Stone Hard Rock Mine Crushing
Price:
USD 81,164.38-95,564.52 one set
MOQ:
1 set
Delivery Time:
20 days
Brand:
BENO
Product Description
Large Throughput Jaw Rock Crusher Low Vibration Hard Rock Crushing
Equipment Description
On the basis of the traditional jaw crusher, the Hydraulic Jaw Rock Crusher adjusts the structure of the equipment, places the motor on the frame close to the belt pulley, and adds a hydraulic device to cushion the vibration of the equipment caused by two jaw crushing objects.
The main components of this Hydraulic Jaw Rock Crusher include frame, eccentric shaft, movable jaw assembly, lining plate, hydraulic device, pulley, motor, etc. The weight of this Hydraulic Jaw Rock Crusher is 39.5 tons, which is the largest equipment in this series. Its production capacity is in the range of 255-808 tons per hour, and it is often used in large mine crushing production lines.
This Hydraulic Jaw Rock Crusher has a large crushing ratio and a large throughput. In order to ensure a good crushing effect, a motor with a power of 160 kW is selected. At this time, the speed of the eccentric shaft is relatively low, which is 240 rpm.
Technical Reference Data
| Model | Feed port size (mm) | Maximum feed particle size (mm) | Adjustment range of outlet (mm) | Production capacity (t/h) | Power (kw) | Rotating speed (r/min) | Weight (t) |
| XCEV408 | 410*1080 | 350 | 40-165 | 50-309 | 75 | 330 | 8.9 |
| XCEV508 | 510*800 | 430 | 40-175 | 50-355 | 75 | 330 | 8.8 |
| XCEV513 | 510*1300 | 430 | 40-180 | 60-410 | 90 | 330 | 15 |
| XCEV515 | 510*1500 | 430 | 40-180 | 65-486 | 110 | 330 | 18.2 |
| XCEV609 | 630*910 | 535 | 50-180 | 80-403 | 90 | 300 | 12.5 |
| XCEV710 | 710*1060 | 600 | 60-200 | 135-485 | 110 | 280 | 18.5 |
| XCEV712 | 760*1150 | 640 | 60-210 | 180-495 | 110 | 260 | 22.4 |
| XCEV810 | 850*1100 | 720 | 80-210 | 205-581 | 132 | 260 | 27.8 |
| XCEV912 | 950*1250 | 810 | 100-250 | 255-808 | 160 | 240 | 39.5 |
Finished Product Picture
