• Top performance in our industry which represent in torque in less than 1hz 0.5hz 0.25hz 0.1hz and 0hz
• it can compare with any domestic chinese brand for output torque.
• Smooth running and stability, support optional LCD keypad and dual display keypad. support PC tools.
• Support modbus485, canopen, profinet communciation.
• Low noise on motor and fast response for 0.1S acceleration and deceleration without dead zone
• Reverse and forward free switching
• Sleeping function and energy saving function as well as in built PLC programming
• Tension control and torque mode control
• Support two group motor parameters which can realize two motor switching control

01. Starting torque: 180% at 0.5Hz (V/f pattern, SVC pattern);

02. Speed adjustable range: 1: 100 (V/f pattern, SVC pattern);

03. Speed accuracy: +/-0.5% (V/f pattern), +/-0.2% (SVC pattern);

04. Over load capability: 150% 1minute, 180% 10seconds;

05. Abundant frequency command sources;

06. Diverse input and output terminals;

07. Ambient temperature: -10°C~50°C;

08. High precise torque constraint, process PID control, multi-speed control, contracting brake control, field weakening control, all sides protection, etc;

09. Online and offline auto-tuning of motor parameters can both performed;

10. Extremely short-time acceleration can be performed without any trip, such as 0.1s or 0s from 0Hz to 50Hz;
