China Portable Cummins Diesel Generator Set 220kva For Outdoor Use for sale

Portable Cummins Diesel Generator Set 220kva For Outdoor Use

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Brand: CNMC

Product Description

Portable Diesel Generator Set 220kva for Outdoor Use

CNMC, It is dedicated to becoming a comprehensive company for intelligent power and green energy supply.Our company aim to create a better life for the world by supplying better power solutions. Continually improving products' quality, friendly-use and durability is our long-term mission. We will make all the efforts to walk a long way to reach customers' greatest satisfaction.

GENSET(5-2500KW Silent, Open, Trailer, Container ect.)
Genset model	GF-20KVA	Rated power	20KVA
Rated Frequency	50/60HZ	Rated Speed	1500/1800RPM
Overall Dimension	18509001100mm(L×W×H)	Gross Weight	750KG
Noise level	72DB	ATS system	GEYA/100A(optional)
ENGINE(Perkins,Cummins, Weichai,Yuchai, FAWDE,SDEC,RICARDO etc.)
Model	490D	Type	In-line,4 Cycle
No. Of Cylinder	4	Bore*Stroke	90 x 115mm
Displacement	3.26 litres	Induction system	naturally aspirated
Rated Out-put	21/23KW	Rated Speed	Mechanical governed 1500 rpm
Fuel Consumption	25% load 1.6 -- 50% 2.1 -- 100 % 3.9	Oil Capacity	11 Litres
Cooling Method	Positive Water Cooling Cycle	Starting Method	D.C 12 V electric starting
ALTERNATOR(China Stamford, original Stamford, Marathon, Leroy Somer, etc.)
Model	PDL164G	Rated Power	20KVA/16KW
Rated Voltage	400 - 415 3 - phase	Rated Current	28.8A
Power Factor	0.8 lagging for 3-phase	Insulation Class	Class H
Phase Connection	3 phase 4 wire/Y type	Excitation Method	100% Copper Brushless alterantor, self-excitation, AVR regulation, IP23
Controller system	ZHONGLING/SmartGen/Deepsea 6120
