KS150 Silenced Type 100mm Chisel Hydraulic Breaker For 10 Ton Excavator
KS150 Silenced Type Hydraulic Breaker 100mm Chisel Diameter Suitable 10~16 Ton Excavator
This is our product brochure. Please download it if you need it. >>>
[ KEISHARP Hydraulic Breaker catalogue.pdf ]
Device Information
| Model Number | KS150 | ||
| Weight | Side | kg | 709 |
| Top | kg | 842 | |
| Silent | kg | 886 | |
| Length | Side | mm | 1946 |
| Top | mm | 2284 | |
| Silent | mm | 2310 | |
| Working flow | L/min | 80~110 | |
| Work stress | bar | 160~170 | |
| Impact frequency | bpm | 350~700 | |
| Brazing rod diameter | mm | 100 | |
| Matching host | t | 10~16 | |
Specification
| Model Number | KS60 | KS80 | KS100 | KS120 | KS150 | KS220 | KS320 | KS350 | ||
| Weight | Side | kg | 170 | 250 | 360 | 597 | 709 | 1900 | 2750 | 3320 |
| Top | kg | 173 | 296 | 396 | 625 | 842 | 2134 | 2995 | 3621 | |
| Silent | kg | 180 | 362 | 466 | 666 | 886 | 1910 | 2610 | 3149 | |
| Length | Side | mm | 1170 | 1398 | 1545 | 1778 | 1946 | 2420 | 2707 | 2860 |
| Top | mm | 1436 | 1598 | 1787 | 2109 | 2284 | 2824 | 3133 | 3370 | |
| Silent | mm | 1446 | 1652 | 1862 | 2140 | 2310 | 2786 | 3161 | 3369 | |
| Working flow | L/min | 20~50 | 40~70 | 50~90 | 60~100 | 80~110 | 130~180 | 180~250 | 210~270 | |
| Work stress | bar | 80~130 | 110~140 | 140~150 | 150~160 | 160~170 | 160~180 | 190~220 | 200~220 | |
| Impact frequency | bpm | 600~1100 | 500~900 | 400~800 | 400~800 | 350~700 | 400~550 | 250~350 | 150~300 | |
| Brazing rod diameter | mm | 53 | 68 | 75 | 85 | 100 | 140 | 155 | 165 | |
| Matching host | t | 2.5~4.5 | 4~7 | 6~9 | 7~14 | 10~16 | 20~27 | 27~35 | 35~40 | |
| Model Number | KS400 | KS450 | KS500 | KS550 | KS600 | KS650 | KS850 | KS1000 | ||
| Weight | Side | kg | 4300 | 5250 | 5350 | 5500 | 6300 | 7900 | 10200 | 12100 |
| Top | kg | 4617 | 6122 | 6242 | 6402 | 7276 | 8151 | 12000 | 14026 | |
| Silent | kg | 4575 | 5300 | 5420 | 5580 | 6052 | 7525 | 11374 | 13400 | |
| Length | Side | mm | 3070 | 3325 | 3330 | 3380 | 3445 | 3710 | 4230 | 4525 |
| Top | mm | 3648 | 3917 | 4026 | 4076 | 4185 | 4295 | 5048 | 5230 | |
| Silent | mm | 3683 | 3904 | 4030 | 4080 | 4212 | 4345 | 5098 | 5280 | |
| Working flow | L/min | 220~280 | 245~290 | 255~300 | 290~340 | 310~360 | 340~440 | 400~530 | 450~580 | |
| Work stress | bar | 200~230 | 270~290 | 270~290 | 280~300 | 280~300 | 290~310 | 290~310 | 290~310 | |
| Impact frequency | bpm | 150~200 | 100~150 | 100~150 | 100~150 | 100~150 | 90~130 | 70~120 | 70~120 | |
| Brazing rod diameter | mm | 175 | 190 | 195 | 200 | 205 | 210 | 230 | 255 | |
| Matching host | t | 40~50 | 45~55 | 50~60 | 50~65 | 55~65 | 65~100 | 80~120 | 90~160 | |
Suitable excavator model
| Brand | XCMG | ZOOMLION | SUNWARD | XGMA | FOTON | LINGONG | STRONG | YUCHA |
|
Model (KS150) |
50 | ZE150E | SWE 90 125 130 150 |
140-8 | 170 | LG6150E | JCM916D GC138 JCM913D MC136-9 |
YC135 |
| SANY | KUBOTA | VOLVO | KOBELCO | HITACHI | HYNUDAI | DOOSAN DAEWOO | KOMATSU | CAT |
| SY135C-8 SY155H |
161 185 |
EC120 EC140 |
SK100 SK120 |
ZX100 ZX130WV ZX150 ZX100WD ZX160WD |
RB130-7 RB175 |
DH130 DH130W DH150 DH170 |
PC120 PC150 PW150 |
212 213 214 E110 |
Technical Characteristics
Usage Scenario
Company Profile
KEISHARP Heavy Industries is a wholly-owned subsidiary of Nikko (China) Co., Ltd., with registered capital of RMB 50 million Yuan and total investment plan of RMB 150 million Yuan. It introduces the latest international technology and related authorized patents, imports a full set of production lines and equipment, integrates 5G IOT and the whole process of heavy machinery R & D and manufacturing technology, implements German lean advanced management strategy. It makes every effort to build a world-leading ecosystem of heavy industry supporting products such as breaking hammers.
Hardware Equipment and Technologies
- Japan complete set of original imported large vertical grinding machine NVG-12LH.
- True simulation of the impact test equipment, industry-leading maximum test 260mm models.
- The core praocessing equipment complete set of original imported HM1000, HM805, PUMA800, PUMA700.
- In association with KEISHARP Heavy Industry, invests 35 million yuan to set up an independent thermal treatment workshop.
FAQ
Q: Are you a manufacturer?
A: We are a professional manufacturer, integrating research and development, production, sales and service in one comprehensive service provider.
Q: How about your products warranty?
A: 12 months warranty for hydraulic breakers and 6 months for spare parts.
Q: Can you produce according to customer's design?
A: Sure, OEM & ODM service available. We are professional manufacturer in Jiangsu.
Q: How about delivery terms?
A: Spot in 5~7 workdays, Order in 10~15 workdays after payment.
Q: How to choose the suitable model?
A: 1. Choose model according to excavator model(Excavator weight) 2. Choose model according to client's country or decided by client himself.
