Product Description:
A vacuum belt filter using three belts can achieve independent speeds and have different belt types for the pressure and gravity zones. This allows the filter system to accommodate higher hydraulic loadings occurring with dilute feed sludge (feed solid concentration below 1.5%). The three belt system is more efficient with both a higher production rate and cake solid concentration at the expense of mechanical complexity.
Significant developments in belt press filter technology include: cloth developments, using three belts and, the V-fold belt. Cloth developments include the double weave which incorporates different yarn types to combine the specific advantages of each. A double weave woven wire belt is also available which has a better life span and durability than a conventional wire belt.
It is mainly consisted and divided into three parts, i.e. cover, carcase, and bottom. For belt filter and other heavy industry and infrastructure construction application, we mainly adopts natural rubber materials with polyester carcase.
At the end of the filtration phase, the cake is removed by means of a knife discharge device.
Features:
| Assembled frame block-design, it is very easy for transportation, installation and maintenance. |
| High automatic control; continuously automatic control of feeding, filtration, washing, dewatering, discharging, cloth washing; improve productivity efficiency; reduce operation cost; reduce the working strength of labors; improve working environment. |
| Convenience filtrating process; by adjusting the thickness of cake, amount of washing water, countercurrent washing grade, vacuum degree and speed of cloth can achieve to a best filtration efficient |
Technical Parameters:
|
Filtration Area (m2) |
Effective Width (mm) |
Effective Length (mm) |
Total Length (mm) |
Frame Width (mm) |
Frame Height (mm) |
Vaccum Consumption (m3/min) |
| 2 | 500 | 4000 | 8100 | 1100 | 2070 | 8 |
| 3 | 500 | 6000 | 10100 | 1100 | 2070 | 12 |
| 8 | 1000 | 8000 | 12100 | 1600 | 2070 | 25 |
| 12 | 1000 | 12000 | 16100 | 1600 | 2070 | 30 |
Applications:
The Vacuum Belt Filter is an ideal solution for slurry treatment in various industries. It is improved and completed during couple of years, the technical characteristics and quality are meet the international advanced level. It is widely applied in metallurgical industry, mine, chemical industry, papermaking, food industry, pharmacy, coal washing, environmental areas, especially in flue gas desulfurization (FGD) for gypsum dewatering and tailings treatment.
Support and Services:
- Installation assistance
- Maintenance and repair guidance
- Operational troubleshooting
- Training for operators and maintenance personnel
- Customized solutions for specific applications
