8CH PM Fiber Array, Polarization Maintaining FA, PM980XP Fiber Array, PMFA.
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
1. Product Overview
This product is an 8-channel PMFA polarization-maintaining fiber array, using Quartz Glass substrate and PM980XP polarization-maintaining fiber. The channel spacing is 250μm, and the polishing angle is 0°.
2. Core Product Features
- 8-channel PMFA polarization-maintaining fiber array design
- 250μm channel spacing, 0° polishing angle
- PM980XP polarization-maintaining fiber
- Insertion loss IL < 0.3dB
- Extinction ratio ER > 18dB
- FC/APC connector, slow axis key
| Parameters | Unit | Spec. | Value |
|---|---|---|---|
| Channel | / | 24 | OK |
| Material | / | Quartz Glass | OK |
| Channel Spacing | μm | 127 | OK |
| Polishing Angle | Degree | 0° | OK |
| Package(L)X(W)X(H) | mm | 12*5.7*1.5 | OK |
| Insertion Loss | dB | ≤0.3 | |
| Extinction Ratio | dB | ≥18 | 25 |
| FA PM Fiber Alignment | / | PMII | OK |
| Connctor PM Fiber Alignment | / | Slow Axis Alignment Key |
OK |
| Fiber Type | / | PM1550(Corning) | OK |
| Fiber Tube | mm | 0.9 | OK |
| Tube Color | / | Blue | OK |
| Length | m | 1±0.1 | OK |
| Connector | / | FC/APC | OK |
| Operating Temperature (℃) | 0～65 | OK | |
| Storage Temperature (℃) | -40～85 | OK | |
3. Applications
- Polarization-maintaining fiber communication systems
- Optical module and optical device coupling
- Fiber laser coupling
- Fiber optic sensing systems
- Coherent optical communication systems
- Laboratory optical path testing and R&D platform
