1/8"-46" Stainless Steel Quick Connect Ball Valve With Clamp Type Ends
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
3-10days
Brand:
YUHAO
Product Description
Stainless Steel Quick-Connect Ball Valve with Clamp-Type Ends
Product Specifications
| Standard | ASTM, JIS, GB, AISI, DIN, BS, EN |
|---|---|
| Bonnet Style | Threaded or Welded |
| Applications | Industrial, Chemical, Oil & Gas, Water Treatment, etc. |
| Thread | BSPT, BSPP, NPT, PS, DIN |
| Port Size | 1/8"-46" |
| Pressure | High/Medium/Low Pressure |
| Color | Silver, Chrome, White, Customer's Request, Grey |
| Brand | YUHAO |
| Temperature of Media | Medium Temperature, Normal Temperature, High Temperature |
| Certificate | CE ISO9001 ISO14001 ISO45001 |
Customizable Durable Stainless Steel Valve Quick-Connect Ball Valve
Premium Stainless Steel Quick-Install Ball Valve
Yuhao's premium stainless steel quick-install ball valves revolutionize pipeline connection efficiency across pharmaceutical, food processing, chemical, and water treatment industries. These high-performance valves combine instant installation convenience with industrial-grade durability for demanding applications.
Key Features & Benefits
- Medical-Grade 316L Stainless Steel - Exceeds ISO 2037, ASME BPE, and 3A Sanitary Standards
- Patented Quick-Connect System - Enables 5-second installation/removal without tools or threading
- Tri-Clamp & DIN Standard Ends - Offers universal compatibility with existing sanitary piping
- Mirror-Polished Interior (Ra≤0.4μm) - Prevents bacterial growth and facilitates sterile cleaning
- Double O-Ring Seal Design - Achieves zero-leak performance up to 10 bar pressure
- Full-Port & Reduced-Port Options - Available in DN15-DN100 sizes for various flow requirements
- CIP/SIP Capable - Withstands 150°C steam sterilization and aggressive cleaning agents
Manufacturing Advantages
- Precision Swiss Machining - Ensures ±0.005mm tolerance for perfect sealing
- In-House Electrochemical Processing - Delivers superior corrosion resistance
- Complete Product Validation - Includes material certs, pressure tests, and surface roughness reports
- Custom Engineering Services - Offers bespoke end connections and special material options
Yuhao's quick-install ball valves represent the perfect marriage of German engineering precision and Asian manufacturing efficiency, delivering unparalleled value to global clients. Our valves have been validated in 500+ installations worldwide, with zero field failure reports to date.
Additional Product Information
| Place of Origin | Zhejiang, China |
|---|---|
| Material | 316, 316L, 304, 304L, Carbon |
| Application | Oil, Water, Industrial, Chemical, Water |
| Size | Customized Size |
| Package | Standard sea worth bundles, Standard Plywood cases |
Product Dimensions
PN1.6MPa Main Connection Dimensions and Weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 280 | 320 | 360 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 180 | 230 | 230 | 400 | 400 | 650 | 1050 | 1050 | 1410 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7 | 10 | 15 | 19 | 33 | 58 | 93 | 160 |
PN2.5MPa Main Connection Dimensions and Weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 320 | 400 | 400 | 550 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 342 | 345 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7.5 | 10 | 15 | 20 | 33 | 60 | 93 | 175 |
PN4.0MPa Main Connection Dimensions and Weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 180 | 200 | 220 | 250 | 280 | 320 | 400 | 400 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 3 | 4 | 5 | 7 | 9 | 12 | 18 | 28 | 46 | 75 | 106 | 190 |
PN6.4MPa Main Connection Dimensions and Weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 165 | 190 | 216 | 229 | 241 | 292 | 330 | 356 | 432 | 508 | 559 | 660 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 305 | 398 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1800 |
| Wt(Kg) | 6.5 | 7 | 8 | 12 | 14 | 18 | 28 | 40 | 65 | 98 | 140 | 250 |
PN10MPa Main Connection Dimensions and Weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 165 | 190 | 216 | 229 | 241 | 292 | 330 | 356 | 432 | 508 | 559 | 660 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 305 | 398 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1800 |
| Wt(Kg) | 6.5 | 7 | 10 | 15 | 18 | 25 | 32 | 46 | 75 | - | - | - |
Product Gallery
Frequently Asked Questions
Q1: How is the quality?
A: Quality is our priority. We pay close attention to quality checks. Every product is fully assembled and carefully tested before packing for shipment.
Q2: What is your minimum order quantity?
A: The MOQ varies by product. Please refer to the product detail page or contact us with the product link for specific information.
Q3: Can I customize products?
A: Yes, we offer customization services. Please provide your specific requirements for a detailed response.
Q4: Do you provide samples? Is it free or extra?
A: Yes, we offer samples free of charge, but customers are responsible for the freight costs.
Q5: How long is your production lead time?
A: Typically 5-10 days for in-stock items or 15-20 days for out-of-stock items, depending on quantity.
