Industrial Grade Resistance Heating Furnace For High Volume Carbide Sintering
Price:
$ 60000-100000
MOQ:
1 Set
Delivery Time:
90 Days
Brand:
Nuotian
Product Description
Vacuum Resistance Furnace Up to 2200℃ Industrial Grade for High-Volume Carbide Sintering
Description:
- Built exclusively for high-throughput industrial production, this 1-to-1 vacuum resistance furnace delivers a stable 2200℃ via premium resistance heating and a sealed vacuum chamber (ultimate vacuum 20Pa). It runs on 380V 3-phase power with SCR control, supporting 24/7 continuous operation to meet mass manufacturing demands.
- Its heavy-duty industrial frame is engineered to resist wear from prolonged production cycles, while the intelligent temperature control system precisely adjusts heating rates and cooling processes to ensure uniform heating across large batches of workpieces. This design minimizes product defects and maximizes yield rates for high-value carbide materials.
- Equipped with automated safety features (vacuum leak detection, over-temperature shutdown, power-off protection) and a user-friendly operation panel, it reduces manual intervention and operational risks, making it ideal for large-scale sintering of tungsten carbide, boron carbide, and silicon carbide components.
Application:
- Tungsten Carbide Manufacturing: Mass production of cutting tools and wear-resistant components.
- Boron Carbide Sintering: High-volume processing of armor plates and industrial abrasives.
- Silicon Carbide Production: Continuous heat treatment for semiconductor and aerospace components.
Specification:
|
Resistance Furnace -- Technology Parameter |
||||||
|
|
Lab usage |
Production usage |
||||
|
NTI-DZL-54W |
NTI-DZL-98W |
NTI-DZL-300w |
NTI-DZL-400W |
NTI-DZL-720W |
||
|
Working size |
mm |
300×300×600 |
350×350×800 |
500×500×1200 |
500×500×1600 |
600×600×2000 |
|
Heating type |
/ |
Resistance heating |
||||
|
Control type |
/ |
SCR control |
||||
|
HT zone capacity |
L |
54 |
98 |
300 |
400 |
720 |
|
Loading weight |
g |
HT zone capacity ×density(g/cm³)×1000 Remark:1L=1000cm³ |
||||
|
IF power |
Kw |
100 |
150 |
300 |
400 |
650 |
|
Ultimate vacuum |
Pa |
20 |
||||
|
Max.working temperature |
℃ |
2300 |
2300 |
2300 |
2300 |
2300 |
|
Usual working temperature |
℃ |
2200 |
2200 |
2200 |
2200 |
2200 |
|
Temperature uniformity |
℃ |
±10 |
±10 |
±10 |
±10 |
±10 |
|
Working environment |
/ |
Vacuum or Ar, Nitrogen atmosphere protection(micro positive pressure) |
||||
Furnace Configuration:
- Control System: Optional 1-to-1 (one control cabinet for one furnace), equipped with Delta PLC for stable, intelligent operation.
Key standard & optional components:
- Vacuum System: Integrated high-performance vacuum unit (including vacuum pump, valve group) to maintain stable vacuum environment during sintering.
- Gas Purifier: High-efficiency gas purification equipment (optional) to filter impurities and ensure clean gas supply for atmosphere-controlled processes.
- Cooling Tower: Optional cooling equipment to achieve efficient heat dissipation, ensuring stable operation of high-temperature components.
- Temperature Measurement: Equipped with Raytek (US) infrared thermometer for real-time, accurate high-temperature monitoring (supports precise temperature control up to 2200℃).
- Air Compressor: Optional auxiliary equipment to provide stable air supply for pneumatic components.
Feature Advantages:
- High-Temperature Capability: Reaches up to 2200℃.
- Vacuum & Resistance Heating: Vacuum environment prevents material oxidation.
- Precise Control: Equipped with FP93 Japanese Shimaden High-Precise Temperature Control System, ensuring stable sintering processes and consistent product quality.
- Versatility: Compatible with a wide range of materials (carbon,ceramics, alloys, c/c,special powders), meeting diverse production needs.
- Safety & Reliability: Equipped with short circuit, over pressure, over-temperature, over current, water shortage, and other protection mechanisms for safe operation.
![]()
After-sales Service:
We provide comprehensive after-sales support to ensure your equipment operates smoothly:
- Warranty: 1-year warranty for core electrical components against manufacturing defects.
- Lifetime Service: Lifetime technical support, including remote troubleshooting, maintenance guidance, and replacement part supply (charged for non-warranty parts).
- Response Efficiency: 24-hour online consultation for urgent issues; on-site service (available globally) can be arranged based on your needs (travel costs extra).
