Industrial High Speed Door With Stainless Steel Structure For Packaging Areas
Industrial High Speed Door With Stainless Steel Structure For Packaging Areas
The Industrial High Speed Door for Packaging Areas with stainless steel structure is specially designed for environments where hygiene, cleanliness, and durability are critical.
In packaging areas, frequent movement of materials and personnel requires fast access without compromising sanitation standards. The stainless steel high speed door offers excellent corrosion resistance, smooth surface finish, and easy cleaning, making it ideal for food, pharmaceutical, and hygienic packaging operations.
Product Specifications
| Material | PVC curtain / Stainless steel |
|---|---|
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.6 - 1.2 m/s (adjustable); Closing Speed: 0.6 m/s (adjustable) |
| Curtain Material | 0.8 - 2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for optimal sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control |
Stainless Steel Hygienic Design
Packaging areas require strict hygiene control.
- Material: SUS304 stainless steel (SUS316 optional)
- Smooth Surface Finish: Reduces contamination risk
- Easy Cleaning: Suitable for disinfectants and cleaning chemicals
- Corrosion Resistance: Ideal for humid or wash-down environments
This design ensures long-term cleanliness and compliance with hygiene standards.
Product Advantages
- Improves packaging efficiency
- Maintains clean and safe working environment
- Reduces energy loss and cross-contamination
- Durable and low-maintenance design
Applications
- Food and beverage packaging areas
- Pharmaceutical packaging workshops
- Consumer goods packaging lines
- Material transfer points
FAQ
Q1: Why use stainless steel high speed doors in packaging areas?
Stainless steel offers superior hygiene, corrosion resistance, and easy cleaning, making it ideal for packaging environments.
Q2: Is the door suitable for wash-down areas?
Yes. The stainless steel structure and sealed design support regular cleaning and wash-down operations.
Q3: Can the door operate frequently during production?
Yes. The servo motor system supports high-frequency operation, ideal for continuous packaging lines.
Q4: Can the door be customized?
Yes. Size, stainless steel grade, curtain type, control system, and safety options can all be customized.
