High Resistivity Thermocouple Cable Type K Colorful Enamelled Wire Cold Rolled
42AWG,40AWG,39AWG colorful bright K type thermocouple wire enamelled wire
The Type T thermocouple wire is composed of a copper (+) wire versus a nickel-45% copper (-) wire. The Type of thermocouple wire is frequently referred to as copper-constantan. This type of thermocouple can be used in oxidizing, reducing, or inert atmospheres with a service temperature range between -200°C and 370°C (-330°F to 700°F). The high temperature use of this thermocouple is also limited due to rapid oxidation of the copper element. The Type T thermocouple wire is one of the few thermocouples which have established limits of error for use in subzero and cryogenic applications. This is possible due to the Type T's superior corrosion resistance in moist environments.
Detailed Parameter of thermocouple wire
| Chemical Composition | ||||
| Conductor Name | Polarity | Code | Nominal Chemical Composition /% | |
| Ni | Cu | |||
Copper |
Positive |
TP |
-- |
100 |
Copper-Nickel |
Negative |
TN |
45 |
55 |
|
Working Temperature Range
|
||
Diameter/mm |
Long time Working temperature /ºC |
Short period Working temperature /ºC |
0.2, 0.3 |
150 | 200 |
0.5, 0.8 |
200 | 250 |
1.0, 1.2 |
250 | 300 |
1.6, 2.0 |
300 |
350 |
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Delivery Detail: By sea/ air. About 7 days, as the order quantity.
1-Enameled Wire( CCA wire, Al. wire, Copper wire)
2-Electric wire( CCA wire, Al. wire, Copper wire)
3-Electric cable( CCA wire, Al. wire, Copper wire)
4-Bare/tinned conductor wire( CCA wire, Al.-alloy wire, Copper wire)
5-Enameling machine(size from 0.02-8.00mm wire)
Advantages:
as the most traditional type of enameled wire, the application field is wide, soldering convenient, performance stable.
Disadvantages:
high cost of production.
Specifications:
Enameled Copper wire
Conductor:copper
Diameter: 0.02-8.00mm
Standard: IEC, NEMA, GB,JIS
Thermal Class: 155 centigrade
Enamelled types : U PEW/F
Certification:UL Approved, iso9001, iso14001,RoHS,REACH
Product details:
| Enameled Type | Polyester | Modified Polyester | polyester-imide | Polyamide-imide | Polyurethane |
| Insulation Type | PEW/130 | PEW(G)/155 | EIW/180 | EI/AIW/200 | UEW/130,155,180 |
| Thermal class | 130, CLASS B | 155, CLASS F | 180, CLASS H | 200, CLASS C | B,F,H CLASS |
| Conductor | Cu | Cu | Cu | Cu | Cu |
| Size(mm) supply | 0.02-8.00 | 0.02-8.00 | 0.02-8.00 | 0.02-8.00 | 0.11-8.0 |
| Enamel thickness | Grade(0,1,2,3) | Grade(0,1,2,3) | Grade(0,1,2,3) | Grade(0,1,2,3) | Grade(0,1,2,3) |
| Standard |
IEC60317-0-2 IEC60317-29 MW36-A SZ Enterprise standard SJ/T11223-2000 |
IEC60317-0-2 IEC60317-29MW36-A SZ Enterprise standard SJ/T11223-2000 |
IEC60317-0-2 IEC60317-29 MW36-A SZ Enterprise standard SJ/T11223-2000 |
IEC60317-0-2 IEC60317-29 MW36-A SZ Enterprise standard SJ/T11223-2000 |
IEC60317-0-2 IEC60317-29 MW36-A SZ Enterprise standard SJ/T11223-2000 |
Product Features:
High breakdown voltage
Good adhesion
Tin soldering
Few pinhole
Sustained and stable quality
Main Applications :
All kinds of household electric motors, vacuum cleaner motor, electric motor
All kinds of transformers, inductors, rectifiers
All kinds of fan motor
All kinds of high frequency electric appliance
Polyester and modified polyester enameled copper wire.
Thermal class 130,155 degree. The product has high mechanical strength, and has good elasticity, adhesion, electrical performance and solvent resistance, which is a poor thermal shock resistance and low moisture resistance. Widely used in a variety of motor, electrical, instrumentation, telecommunications equipment and home appliances.
