Office Temporary Divider Aluminum Frame Sliding Folding Movable Wall Partitions
Office Temporary Divider Aluminum Frame Sliding Folding Moveable Wall Partitions
Moveable Wall Partitions Operation
1. How to fix multi-directional moveable wall partitions?
Hold the screen with one hand and insert the handle into the hexagonal steel at 1100mm on the side of the screen. Grab the handle and turn it clockwise by 180 degrees. The retractable seal inside the screen will pop out to fix the screen and insert the handle. The groove on the side of the hotel partition, pull the handle upwards to open the retractable seal fixed screen inside the screen, the hotel partition screen put the whole set of screens and check whether the screen is straight and whether it is on the same plane as the rail, if not straight Then retract the upper and lower retractable seals to adjust until the screen is straight.
2. How to open the partition screen of moveable wall partitions?
All operations should be gentle and safe. Stand facing the screen and grab both sides of the screen with both hands. Pull the screen along the rail, and then turn the screen along the rail to push the hotel partition to its proper position. Fix the screen.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Moveable Wall Partitions Features
Individual panels that can be stored away for maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hung and no floor track.
Extensive range of moveable wall partitions surface finishes can be availabled.
