Comfortable Athletic Track Surfaces / Soft Synthetic Athletic Track
Comfortable Athletic Track Surfaces / Soft Synthetic Athletic Track
Synthetic running track features:
1. A full new revolutionary sports flooring material
2. No need to add any chemical ingredients. Easy to construct
3. A poured-in-place track surface that is impermeable and installed in a multi-layered application.
4. The base layers consist of two-component polyurethane and recycled rubber.
5. The top layer is a flow-applied layer of two-component polyurethane with EPDM granules.
Athletic Track Surfaces Specifications
|
Product |
Athletic Track Surfaces |
||
|
Thickness |
13 mm or customized |
||
|
Force Reduction |
41 |
||
|
Tensile Strength |
1.56 |
||
|
Elongation at break |
92 |
||
|
Modified Vert. Deform. |
1.9 mm @ 23°C [75°F] |
||
|
Friction |
0.64/48 |
||
|
Material |
EPDM, SBR, Reclaimed Rubber, ETC. |
||
|
Features |
Environmental-friendly, UV-resistance, 5--10 years service time |
||
|
Market |
North America, Southeast Asia, Western Europe, Domestic Market |
||
|
Application |
Outdoor Rubber Track, Playground Sports Flooring,etc. |
||
|
More Test Data |
|||
|
Test Item |
Reference |
Standard Data |
Test Result |
|
Tensile |
IAAF |
≥0.5 |
1.56 |
|
Elongation at Break |
IAAF |
≥40 |
92 |
|
Force Reduction |
IAAF |
35-50 |
41 |
|
Vertical Deformation |
IAAF |
0.6-2.5 |
2.3 |
|
Skid Resistance |
IAAF |
≥47 |
57 |
|
Hardness Shore A |
GB/T 14833-2011 |
45-60° |
45-55° |
|
Fire Rating |
GB/T 14833-2011 |
I Degree |
I Degree |
|
Color Stability |
|
|
Good |
|
Chemical Resistance |
|
|
Good |
Athletic Track Surfaces Description
The running track or say all-weather athletic running track, is made from PU, synthetic material, including paint, additive, anti-oxygen additive, anti-aging additive, filling, rubber and so on. The surface of running track is made by EPDM rubber granule or PU granule. Plastic and rubber running track is good for sportsmen’s speed and technique, effective for improving sporting achievement, useful for protecting sportsmen form falling down with features of flatness, anti-press, good elasticity, steady performance of physic and chemistry, stand and long-lasting color, long using life. From the pattern, they can be divided into mixing, ventilate, compound and so on. From the appearance, they can be divided into of granule, non-granule, ready-made. The running track can be painted in red, or green, or blue. There are 13mm in competition area, 9mm in non-competition area. For adding thickness area, it is 20-25mm. Running tracks are recognized as the best all-weather sports ground material in the world. Our running track products have been certificated by IAAF. We can supply the professional and all-round service for you from material to installing technique and technician to installing machines
Structure: 2mm thickness spray paint top layer plus 11mm thickness PU glue mix SBR
rubber particle on the Bottom
Our Services
Best service: Any inquiry will be replied in 24 hours. Timely and professional service all the time.
Best price: Reliable factory , direct selling,charming price for you!
Free sample: Provide free sample within 2kg, you just need to pay for the sample Express fee.
After-sale service: Provide free trainning lesson for our oversea distrubitor or buyer, professional
product & construction knowledge for you.
Mixing-type Running Track
1. Introduction: The construction is recognized by IAAF. The sports court has comfortable,
exciting feeling because of the brightly colored sports ground. It is good to improve success it can meet the requirements for professional competitions.
2. Characteristic: unaffected by the climate, high strength, anti-friction, flat, shockproof, anti-skid, elasticity, low temperature and suitable hardness.
3. Foundation requirement:
(1). Asphalt base need to have no crack, no roller compaction traces, no asphalt block ,no oil stain, no dent, no honeycomb and so on.
(2). No block water in basic surface.
(3). Planeness: more than 95% and the acceptable deviation is ±3mm for 3m ruler.
(4).Slope: 5‰-8‰
(5).Density: The density is above 97%.
(6).Water absorption: 6-10%
(7). Maintenance period: above 28℃,more than 28 days.
(8). Please make sure the drainage system in advance
Running Track
