PVC PP PE Vertical Screw Mixer For Plastic Pellet Homogenizer Recycling Mixer

Features:

1. The design of this machine is made by two-stage propeller output fast , the first stage put the raw

    material into barrel inside , then the second stage lift the raw material to the upper of the barrel body by

    rapid elevation . the material will be scattered and flied like the shape of umbrella , the hot air blows out

    from the center of barrel bottom to surrounding ,upward penetrate smoothly across the gap of moving

    raw material , carry on the all-round heat exchange during dynamic drying processing .
2. This machine has multi-function feature , because of the material has been non-stop cycle in the

    barrel,and the hot air output from the center , so as to achieve the effect of both mixing and drying . if

    you do not need drying function , just close the button of "heating ", then only single function left . this

    machine can select multi-function for granular material or granular and powder mixing material .
3. Barrel body , shaft , rotating blade,inlet feed ,outlet feed, barrelhead are all made of stainless steel.

Specifications:

Instructions :

1. Idling before you power on the machine ,Check whether the machine is running.
2. After working properly,Set the mixing time(According to the different materials in different time)
3. Pour the material into the inlet feed gate.(notice :Middle of material added to the view-feed gate, not too

    full)
4. After mixing evenly,Open the outlet feed gate and release the material.

Notice :

1. Do not open the lid when the machine is in normal operation.
2. After 2-3 months machine running, maintainance (The upper and lower bearings need to add grease)

Installation and commissioning :

Before leaving the factory by the professional and technical person testing machine and debugging successfully before shipment. equipment can be used after received by customer then directly connected with the power supply .

FAQS:

Q1. Which material can be used for the machinery ?
All the machinery produced by our company is made of stainless steel which eliminates rust corrosion and easy to clean, prevent your material from contamination of foreign substances. Also it makes a more beautiful look.

Q2. How can I control the quality of the goods?
We have strict quality control in production process.
And we also offer the time plan of the production state to you every time , you can see every step of your machinery to be made in detail . High quality is our stander to make sure that we could establish long -term business with our customers instead of Short-sighted benefit .

Q3. How about the lead time ?
This part is our strongest part , for meeting the customers big demands , we have some products in stock which will certainly help our customer to save their time and increase the production capacity . Also if the products is out of stock , we will try our best to meet make the products at earliest time , about 20 days . And each machinery will have a specific time schedule to ensure about the customer know all the detail and have good plan for preparation work .

Q4. About Shipment.
If you have your own forwarder. We can deliver the goods to your forwarder's warehouse.
We also have good cooperated forwarder, if you are not convenient at this part, we can arrange our forwarder to ship the goods to you.
