SUS304 Stainless Steel White Medium-intensity Type A Solar Aviation Obstruction Light
SUS304 Stainless Steel White Medium-intensity Type A Solar Aviation Obstruction Light
Advantages
1. International advanced solar panel reaching more than 10 years service life.
2. Comprehensive protection in voltage short circuit, over-voltage, floating Charge and temperature.
3. Low power consumption profession flash switch.
4. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
5. Strong impact lamp shape with PC material.
6. Strong anticorrosion and UV protection.
7. At least 7 days autonomy.(optional 15days)
8. Having lightning-protection function.
9. Side open of battery box can be open for maintenance convenience very easily.
10. New technology application. Light can work at night automatically by solar panel which function is equal to photocell sensor.
Datasheet: AH-MS-A Medium-intensity Type A L865 Solar Aviati...
Detail Description:
This product is single solar light. Installed in the fuse, it can control flash all day automaticly by Solar panel which function is equal to photocell sensor. Side on battery box can be opened to be convenient for maintenances. At night,White Flashing mode,20 to 60 times/minutes,2,000cd;During the day,White Flashing mode,20 to 60 times/minutes,20,000cd.
Application:
Scope of Application
AH-MS/A Medium-intensity Type A Solar-Powered Aviation Obstruction Light can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations, Electric Tower, High-rise Building, High Chimney, marking towers (Telecom,GSM, Microwave &TV), High Pole, Tower Crane, Wind Turbine, etc especially which are hard to lay the cable or lack of power supply as well as those facilities which have high requirements on lightning protection.
Specifications:
| SPECIFICATIONS | AH-MS/A Medium-intensity Type A Aviation Obstruction Light |
| Light Characteristics | |
| Light Source | LED |
| Emitting Colors | White |
| Intensity(cd) |
2,000cd (Night) 20000cd(Daytime) |
| Horizontal Output(degrees) | 360 |
| Vertical Divergence(degrees) | 3 |
| Reflector Type | Fresnel Lens |
| Flash Frequency | Flashing mode(40-60times/minute) |
| Operation Mode | Dusk-to-dawn Automatically as standard. |
|
LED Lifetime Experience(hours) |
>100,000 |
| Electrical Characteristics | |
| Working Voltage |
DC 12V (Solar powered Way), recyclable batteries with the lightest environmental and long life.
|
| Power(W) | 60 |
| Circuit Protection | Integrated |
| Temperature Range(℃) | -40~60 |
| Physical Characteristics | |
| Body Material | Aluminum Alloy |
| Base Material | Die-casting aluminum |
| Mounting | 580 by 580 by Φ13 |
| Height(mm) | 1390 |
| Width(mm) | 1350 |
| Depth(mm) | 615 |
| Mass(kg) | 42 |
| Product Life Expectancy | 5 years plus |
| Environmental Factors | |
| Humidity | 10%-95% |
| Wind Speed | 80m/s |
| Waterproof | IP65 |
| Compliance | |
| ICAO | Medium-intensity Type A Solar Aviation Obstruction Light, ICAO Annex 14 Volume 1,'Aerodrome Design and Operations’ Forth edition July 2004,table6.3 |
| FAA | Medium-intensity Type A FAA L-865 |
Dimension Drawing
Product Picture
