Brass Universal Type Mold Shut Off Coupling Rectus 86/87/88 series
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
7-20 work days
Brand:
carterberg
Product Description
Universal Type Mold Quick Couplings Rectus 86/87/88 series Shut Off Quick Coupling
Features:
1. Ball locking mechanism
2. Non-valved couplers have minimum flow resistance for maximum cooling
3. Couplers and nipple are precision machined from solid bar stock.
4. Widest choice of end fittings available, including straight,Elbow with standard hose barb or Push-Lok barbs for easy installation.
5. Interchange:Parker Moldmate Series ,Rectus 86/87/88 series.
| BODY SIZE | Rated Pressure (Mpa) | Rated Flow (L/min) | Temperature Range(FKM) |
| 2" | 15 | 11.5 | -20℃~+200℃ |
| 3" | 15 | 23 | |
| 4" | 15 | 45 | |
| Silicone | Temperature | -60℃~+200℃ |
Our Services:
| 1. Customized design, OEM is available. |
| 2. In-time & professional after sales service. |
| 3. Low MOQ, standard package, fast delivery. |
| 4. Special discount and protection are provided to our distributors. |
| 5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature. |
