Automatic UHT Sterilization Machine Tubular Type For Milk Juice Liquid
Milk juice liquid UHT full - automatic tubular type sterilizer equipment
Product Description
1. The host of automatic tube sterilizer of fresh fruit juice is tube type high temperature sterilizer. The machine has characteristics such as compact structure, effective sterilization, convenient operation, wide adaptation, low cost and so on. According to users’ needs, it can be supplied separately UHT sterilization system, including tube-type sterilizing machine, preheating tank, and insulation tank, the homogenizer interfaces can prevent formatting milk stone, with the pasteurization function. It can also available the entire unit, including UHT sterilizing system and flash degassing system.
2. The host of automatic tubular pasteurizer system is tube type high temperature sterilizer. The machine has characteristics such as compact structure, effective sterilization, convenient operation, wide adaptation, low cost and so on. According to users’ needs, it can be supplied separately UHT sterilization system, including tube-type sterilizing machine, preheating tank, and insulation tank, the homogenizer interfaces can prevent formatting milk stone, with the pasteurization function. It can also available the entire unit, including UHT sterilizing system and flash degassing system.
3. Design specification
Usage:sterilization of liquid product
Effect:commercial sterilization
Sterilization temperature: 135°C
Process parameter:
A Sterilized milk :5°C→65°Chomogeneity→95°C(30S)
B. Sterilized soya milk:65°Chomogeneity→135°C(15S)→28°C
C. Fresh juice:25°C→105°C(10S)→90°C→40°C backflow
5. Characteristics :
Not easy coking, longer producing time
Material is reliable, high operating pressure
The product can bring grain, suitable for high viscosity material processing
Easy to clean, low maintenance cost
PLC control, with the man-machine interface, easy operation
Import and export temperature easy to control
|
Fruit juice pasteurizer |
UHT-1 |
UHT-2 |
UHT-3 |
UHT-4 |
UHT-5 |
|
Product capacityT/h |
1 |
2 |
3 |
4 |
5 |
|
Heat exchanging area m2 |
16 |
26 |
38 |
46 |
56 |
|
Materal inlet temperature ºC |
5 |
5 |
5 |
5 |
5 |
|
Materal inlet temperature ºC |
5 |
5 |
5 |
5 |
5 |
|
Sterilizing temperature |
137 |
137 |
137 |
137 |
137 |
|
137Warmkeeping timeS |
4 |
4 |
4 |
4 |
4 |
|
Ice water temperature ºC |
1 |
1 |
1 |
1 |
1 |
|
Ice water cos T/h |
3 |
4 |
6 |
8 |
12 |
|
Jiont size mm |
φ 25 |
φ 38 |
φ 38 |
φ 51 |
φ 51 |
|
Weight kg |
980 |
1080 |
1160 |
1350 |
1680 |
|
Size mm |
1500 * 1500 |
1900 * 1800 |
1900 * 1800 |
1900 * 1800 |
2600 * 2200 |
|
power kw |
3 |
4 |
5 |
6 |
6 |
FAQ
| 1. Delivery ? |
| 20 - 30 working days after get your advance payment . |
| 2.Payment : |
| Western Union,TT , 50% in advance ,the rest before shipment . |
| 3. Price available ? |
| FOB CIF CNF CFR Shanghai/Ningbo China . |
| 4. Can we visit your factory . |
|
Yes , welcome to visit our factory .We can talk face to face and you can check the quality by yourself . |
| 5. How to know the technical details of the UHT Sterilizer ? |
|
Send your inquiry ,we will give you full details with our quotation . |
| 6.Do you have other type UHT sterilizer ? |
| Yes , we have picture for your reference. |
Our Services
1. Quotation can be available within 1 hours after we get your reply .
2. We provide lifelong technical service.
If the customer needs, we can provide the engineer overseas technical service.Salary negotiable.
