BRPV3-1000 DC Surge Protection Device 1000v
Features:
Application:
Designed especially for surge protection of the PV strings, apply to the Photovoltaic power grid-connection system.
Used for PV systems with or without separate lightning protection system.
Used to protect the sensitive line of the solar power generation protection device.
It widely used in PV DC combiner box, inverter, controller and PV DC cabinet.
Features:
- Product Name: DC Surge Protection Device
- Response Time: ≤25ns
- Storage Temperature Range: -40℃~+85℃
- Rated Voltage: DC
- Voltage Protection Level: ≤4.0kV
- Maximum Continuous Operating Voltage: ≤DC 1000V
- Special Feature: Solar Surge Protective Device (SPD)
Technical Parameters:
| Attribute | Specification |
|---|---|
| Operating Temperature Range | -40℃~+85℃ |
| Cross-section area (Max.) | 35mm² |
| Maximum Discharge Current | 40KA(8/20μs) |
| Maximum Continuous Operating Voltage | ≤DC 1000V |
| Cross-section area (Min.) | 4mm² |
| Enclosure material | Thermoplastic UL94-V0 |
| Operating state | Green / Red |
| Storage Temperature Range | -40℃~+85℃ |
| Product Name | DC Surge Protection Device |
| Response Time | ≤25ns |
Applications:
Customization:
Model Number: BRPV3-1000
Place of Origin: China
Certification: TUV/CB/CE/ROHS/ISO9001
Minimum Order Quantity: 1PCS
Packaging Details: carton
Delivery Time: 15 days after receipt of deposit
Payment Terms: TT
Supply Ability: 1000000 per month
Response Time: ≤25ns
Cross-section area (Min.): 4mm²
Product Name: DC Surge Protection Device(SPD, Lightening Protector)
Voltage Protection Level: ≤4.0kV
Operating Temperature Range: -40℃~+85℃
Support and Services:
DC Surge Protection Device offers technical support and service to ensure that the product is installed and operated properly. Our technical support team is available 24/7 to answer any questions or concerns you may have about the product.
We provide comprehensive support services such as telephone and email assistance, troubleshooting, installation and maintenance services. Our team of experienced technicians are knowledgeable about the product and can help you with any technical issues you may have.
We also provide regular updates and upgrades to ensure that your DC Surge Protection Device is always up to date and functioning optimally. We provide a warranty on the product to guarantee its quality and performance.
If you have any questions or concerns about the DC Surge Protection Device, please do not hesitate to contact our technical support team.
