Low Head 25m Landscape Fountain Water Pump For All Purpose
Low head 25m landscape fountain water pump for all-purpose
Application range of Low head 25m landscape fountain water pump for all-purpose:
The special pump for fountain is applicable to all kinds of garden waterscape projects, chemical plants, salt farms, marine sewage and the unique natural environment of mining, and can also be used to transport slightly corrosive liquids.
Service conditions of Low head 25m landscape fountain water pump for all-purpose+:
1. When the rated lift of the special pump for landscape fountains is less than 10 meters, the allowable depth of submergence into the water shall not exceed 10 meters.
2. When the rated lift of the electric pump exceeds 10m, the allowable depth of submergence into the water shall not exceed 40m.
3. The material temperature shall not exceed+40 ℃.
4. The sand content in the water or the volume ratio of solid particles containing insoluble water shall not exceed 0.1%.
5. The particle size distribution shall not exceed 0.2mm.
6. Cold water under normal temperature, such as river water, river or slightly corrosive liquid.
7. The switching power supply shall be three-phase 50Hz, with a rated current of 380V. The working voltage of its power supply system must be within 342~420V.
8. The electric pump shall be applied in the application field around the rated lift.
9. The electric pump shall be equipped with relative starting protection device and grounding device.
Storage conditions of Low head 25m landscape fountain water pump for all-purpose:
When the electric pump is not used for a long time, the water in the motor shall be drained in time, the surface shall be wiped clean, coated with anti-rust oil, and placed in a clean, dry place without chemical corrosion. After the inner chamber of the motor is filled with clean water, it is strictly prohibited to put it under the environmental conditions with a temperature of 0 ℃ or below, or it must be completely drained to prevent the motor from freezing and cracking.
Parameters of Low head 25m landscape fountain water pump for all-purpose:
| Model |
Capacity (m3/h) |
Head (m) |
Power (kw) |
| QSP25-25-3 | 25 | 25 | 3 |
| QSP45-25-5.5 | 45 | 25 | 5.5 |
| QSP65-25-7.5 | 65 | 25 | 7.5 |
| QSP45-25-5.5 | 45 | 25 | 5.5 |
Our company provides various types of QS(P) fountain submersible pump with the following parameters:
| Model |
Capacity (m3/h) |
Head (m) |
Power (kw) |
| QSP15-26-2.2 | 15 | 26 | 2.2 |
| QSP20-20-2.2 | 20 | 20 | 2.2 |
| QSP25-17-2.2 | 25 | 17 | 2.2 |
| QSP65-7-2.2 | 65 | 7 | 2.2 |
| QSP100-5-2.2 | 100 | 5 | 2.2 |
| QSP40-16-3 | 40 | 16 | 3 |
| QSP40-18-3 | 40 | 18 | 3 |
| QSP45-16-3 | 45 | 16 | 3 |
| QSP25-25-3 | 25 | 25 | 3 |
| QSP32-20-3 | 32 | 20 | 3 |
| QSP50-13-3 | 50 | 13 | 3 |
| QSP65-10-3 | 65 | 10 | 3 |
| QSP22-28-3 | 22 | 28 | 3 |
| QSP50-13-3 | 50 | 13 | 3 |
| QSP100-7-3 | 100 | 7 | 3 |
| QSP15-34/2-3 | 15 | 34 | 3 |
| QSP20-30/2-3 | 20 | 30 | 3 |
| QSP40-21-4 | 40 | 21 | 4 |
| QSP65-13-4 | 65 | 13 | 4 |
| QSP80-12-4 | 80 | 12 | 4 |
| QSP100-9-4 | 100 | 9 | 4 |
| QSP25-34/2-4 | 25 | 34 | 4 |
| QSP24-34/2-4 | 24 | 34 | 4 |
| QSP15-52/3-4 | 15 | 52 | 4 |
| QSP20-40/2-4 | 20 | 40 | 4 |
| QSP20-36/2-4 | 20 | 36 | 4 |
| QSP30-26/2-4 | 30 | 26 | 4 |
| QSP40-28-5.5 | 40 | 28 | 5.5 |
| QSP45-25-5.5 | 45 | 25 | 5.5 |
| QSP60-20-5.5 | 60 | 20 | 5.5 |
| QSP65-18-5.5 | 65 | 18 | 5.5 |
| QSP40-30/2-5.5 | 40 | 30 | 5.5 |
| QSP30-36/2-5.5 | 30 | 36 | 5.5 |
| QSP30-38/2-5.5 | 30 | 38 | 5.5 |
| QSP30-40/2-5.5 | 30 | 40 | 5.5 |
| QSP20-50/3-5.5 | 20 | 50 | 5.5 |
| QSP15-65/4-5.5 | 15 | 65 | 5.5 |
| QSP120-10-5.5 | 120 | 10 | 5.5 |
| QSP100-12-5.5 | 100 | 12 | 5.5 |
| QSP220-5-5.5 | 220 | 5 | 5.5 |
| QSP65-25-7.5 | 65 | 25 | 7.5 |
| QSP80-24-7.5 | 80 | 24 | 7.5 |
| QSP100-15-7.5 | 100 | 15 | 7.5 |
| QSP150-10-7.5 | 150 | 10 | 7.5 |
| QSP40-40/2-7.5 | 40 | 40 | 7.5 |
| QSP80-22/2-7.5 | 80 | 22 | 7.5 |
| QSP30-50/3-7.5 | 30 | 50 | 7.5 |
| QSP30-54/3-7.5 | 30 | 54 | 7.5 |
| QSP25-56/3-7.5 | 25 | 56 | 7.5 |
| QSP50-36/3-7.5 | 50 | 36 | 7.5 |
| QSP20-75/3-7.5 | 20 | 75 | 7.5 |
| QSP25-60/3-7.5 | 25 | 60 | 7.5 |
| QSP24-34/2-4 | 24 | 34 | 4 |
| QSP15-52/3-4 | 15 | 52 | 4 |
| QSP20-40/2-4 | 20 | 40 | 4 |
| QSP20-36/2-4 | 20 | 36 | 4 |
| QSP30-26/2-4 | 30 | 26 | 4 |
| QSP40-28-5.5 | 40 | 28 | 5.5 |
| QSP45-25-5.5 | 45 | 25 | 5.5 |
| QSP60-20-5.5 | 60 | 20 | 5.5 |
| QSP65-18-5.5 | 65 | 18 | 5.5 |
| QSP40-30/2-5.5 | 40 | 30 | 5.5 |
| QSP30-36/2-5.5 | 30 | 36 | 5.5 |
| QSP30-38/2-5.5 | 30 | 38 | 5.5 |
| QSP30-40/2-5.5 | 30 | 40 | 5.5 |
| QSP20-50/3-5.5 | 20 | 50 | 5.5 |
| QSP15-65/4-5.5 | 15 | 65 | 5.5 |
| QSP120-10-5.5 | 120 | 10 | 5.5 |
| QSP100-12-5.5 | 100 | 12 | 5.5 |
| QSP220-5-5.5 | 220 | 5 | 5.5 |
The fountain pumps produced by our company have been recognized internationally, and each pump has passed the quality inspection. In addition, our pump products have also obtained ISO 9001, TUV, BV, CE, 3C certification. We are a factory specializing in the production of water pumps for more than 30 years. We have a one-to-one service team to help you quickly and high-quality model selection. Our email is enquiry02@apkpump.com, our Whatsapp is +86 17537187726. Thanks to contact us.
