Big Flow 30hp Multistage Submersible Borehole Pump
30hp big flow multistage centrifugal irrigation deep well submersible water pump for bore well pumps
30hp water submersible pump overview:
1. Diameter: 7 8 10 12 inch submersible pump
2. Flow: 18-257m3/h
3. Head: 18m-232m
4. Power: 22kw30hp
5. Voltage: 380v/440v/480v/600v/660v
6. Material: Cast iron/stainless steel 304/316/316l /duplex stainless/904l
Submersible water pump parameters:
|
Diameter
|
Model
|
Power
|
Flow range
|
Head range
|
|
|
Inch(")
|
QJ type
|
kw
|
hp
|
m3/h
|
m
|
|
8"
|
200QJ20-189/14
|
22
|
30
|
18-22
|
160-217
|
|
8"
|
200QJ20-202/15
|
22
|
30
|
18-22
|
172-232
|
|
8"
|
200QJ25-168/12
|
22
|
30
|
23-27
|
140-195
|
|
8"
|
200QJ25-182/13
|
22
|
30
|
23-27
|
150-210
|
|
8"
|
200QJ32-128/8
|
22
|
30 |
29-35
|
106-150
|
|
8"
|
200QJ32-130/10
|
22
|
30
|
29-35
|
108-155
|
|
8"
|
200QJ32-143/11
|
22
|
30
|
29-35
|
121-170
|
|
8"
|
200QJ32-144/9
|
22
|
30
|
29-35
|
123-172
|
|
8"
|
200QJ40-117/9
|
22
|
30
|
37-43
|
94-140
|
|
8"
|
200QJ50-90/6
|
22
|
30
|
46-54
|
72-108
|
|
8"
|
200QJ50-91/7
|
22
|
30
|
46-54
|
73-110
|
|
8"
|
200QJ63-70/5
|
22
|
30
|
58-68
|
60-82
|
|
8"
|
200QJ80-66/6
|
22
|
30
|
74-86
|
56-75
|
|
8"
|
200QJ100-45/3
|
22
|
30
|
80-120
|
42-47
|
|
10"
|
250QJ63-80/4
|
22
|
30
|
58-68
|
68-92
|
|
10"
|
250QJ80-60/3
|
22
|
30
|
74-86
|
51-69
|
|
10"
|
250QJ160-30/2
|
22
|
30
|
148-172
|
25-35
|
|
12"
|
300QJ240-22/1
|
22
|
30
|
223-257
|
18-25
|
FAQ:
1. What is your MOQ?
Normally our MOQ is 1.
2. Can you offer sample?
Yes, we can provide samples for testing
3. What is your delivery time?
We wil deliver in 15-20 work days
Applications:
1. Ground water pumping
2. Irrigation system
3. Sea water, shipyard, offshore, floating dock, salt water
4. Drawing water from well
32m3/h 144m 30hp water submersible pump
80m3/h 60m 30hp submersible water pump
160m3/h 30m SS904L water submersible pump
Storage:
1. Shenlong Pump has three complete casting lines, including Expendable casting process, wax casting mold, coated sand, it can meets the different requirements on the dimensional accuracy of casting. The wax casting mold line, special for stainless steel material, was finished in the thermostatic workshop to guarantee the casting accuracy, meanwhile, shorten the whole production time.
2. More than 85 sets production machine, includes grinding machine, CNC, lathe, Milling, High speed punch press machine, testing machine, with sufficient spare parts stock to guarantee the production capacity 11,000 sets per month. From material purchase, metalworking, impeller dynamic balance, motor winding, insulation and pump assembling, passed more than 27 inspection processes, to ensure the quality meet a criterion.
Packing And Shipping:
1. Package: 3 layers of packaging with 8mm special export wooden box, Shock absorption,moisture-proof package
2. Shipping: by sea freight, air, express
