Large Size Ceramic Structured Packing / Ceramic Raschig Rings For Tower Packing
Ceramic Random Packing Ceramic Raschig Ring For Tower Packing
Ceramic Raschig rings, Simple shape, it is the same height and diameter of the ring. Raschig rings large size (≥100mm) are structurally packed in the column, for small size<100mm below the Raschig rings and more filled with heaps way. Ceramic Raschig Rings with excellent acid resistant properties, the ability of reisting various inorganic acid, organic acids and organic solvents corrosion(except HF acid), high temperature in a variety of occasions, wide range of applications, can be used for chemical industry, metallurgy, gas and environmental protection industries in the drying tower, absorption tower, cooling tower, scrubber, regeneration tower.
Specification of Cermic Rasching Ring:
| Diameter (mm) | Size (mm) | Surface Area (m2/m3) | Void (%) | Number (pcs/m3) |
| 6 | 6×6×1.0 | 700 | 57 | 2640000 |
| 8 | 8×8×1.5 | 490 | 62 | 1210000 |
| 10 | 10x10x2 | 400 | 67 | 750000 |
| 20 | 20×20×2.5 | 230 | 70 | 96000 |
| 25 | 25×25×3.0 | 200 | 71 | 42000 |
| 50 | 50×50×2.5 | 105 | 73 | 5200 |
| 76 | 76×76×3.0 | 80 | 74 | 2260 |
| 100 | 100×100×8.0 | 66 | 76 | 1000 |
| 150 | 150×150×15.0 | 40 | 70 | 283 |
Features: excellent acid resistant properties, the ability of reisting various inorganic acid, organic acids and organic solvents corrosion(except HF acid), high temperature in a variety of occasions, can be used at various high temperatures
Application: wide range of applications, can be used for chemical industry, metallurgy, gas and environmental protection industries in the drying tower, absorption tower, cooling tower, scrubber, regeneration tower.
