304 Metal 250Y Structural Packing Column For Desulfurization Tower High Performance
304 Metal 250Y Structured Packing for Desulfurization Tower
Supply Ability
Supply Ability:
30000 Cubic Meter/Cubic Meters per Year
Packaging & Delivery
Packaging Details
Composite material box, wood box or custoer request
Port:SHANGHAI or on request
Lead Time :
|
Quantity(Sets) |
1 - 30 |
>30 |
|
Est. Time(days) |
7 |
To be negotiated |
Product Features
The structure packing, suitable for a wide range of applications include rectification,
absorption, stripping, flashing, mass transfer and etc.
The "Zero wall flow" technics is the key point of our structure packing.
We had a test before.
We found that when use the normal structure packing, the wall-flow in the packed column
is more than 30%.So that the loss ratio of the separate efficiency is 15-24%.
But our ZWF structure packing can keep the wall flow below 2%.
| Type | Specific Area | Void | F factor | Theoretical plate | Pressure drop |
| m2/m3 | m3/m3 | No/m | mmHg/m | ||
| ST-A-125X/Y | 125 | 98.50% | 3 | 270 | 94 |
| ST-A-250X/Y | 250 | 97% | 2.6 | 230 | 96 |
| ST-A-350X/Y | 350 | 95% | 2 | 150 | 97 |
| ST-A-450X/Y | 450 | 93% | 1.5 | 120 | 98 |
| ST-A-500X/Y | 500 | 92% | 1.4 | 87 | 99 |
