2 Core HV Small Current Straight Plug Waterproof Connector for EV/NEV
2 Core HV Small Current Straight Plug Waterproof Connector for EV/NEV
Product Definition
This is a 2-pin (two-core) high-voltage straight plug connector designed for new energy electric vehicles (NEVs/EVs), energy storage systems, and other high-voltage power transmission applications. It features a robust orange housing (HV safety standard), waterproof and dustproof design, and a straight inline mating interface with crimp or snap-lock connection. Ideal for reliable, safe, and vibration-resistant high-voltage connections in demanding automotive and industrial environments.
Technical Parameters: 2-pin high voltage connector
| Parameter | Specification |
| Number of Pins | 2 Pin (2-Core) |
| Connector Type | Straight Plug |
| Gender | Male Plug (can pair with Female Socket) |
| Rated Voltage | High Voltage (typically 600V~1500V DC) |
| Rated Current | Small to Medium Current (typically 20-60A) |
| Color | Orange (HV Standard) |
| Protection Level | IP67 / IP6K9K Waterproof & Dustproof |
| Connection Method | Crimp / Snap Buckle (Tool-free) |
| Operating Temperature | -40°C ~ +125°C / +130°C |
| Housing Material | High-performance Flame-retardant Plastic |
| Application | New Energy Vehicle, Energy Storage, Rail |
Key Features
- High Voltage Safety: Orange HV warning color, excellent insulation, and touch-proof design.
- Excellent Waterproof Performance: IP67 or higher rating, suitable for harsh outdoor and automotive conditions.
- Straight Plug Design: Easy direct insertion, space-saving for compact wiring harnesses.
- Quick & Reliable Connection: Crimp/snap buckle (免焊接卡扣), tool-free assembly, secondary locking mechanism.
- Durable & Vibration Resistant: High-quality engineering plastics and seals for long-term reliability in vehicles.
- Cost Effective Bulk Pricing: Competitive wholesale price with high stock availability.
- Wide Application: Perfect for EV battery systems, motor controllers, chargers, and energy storage.
Application Scenarios
- Battery Pack to PDU / Motor Controller connections in electric vehicles
- On-Board Charger (OBC), DC-DC Converter, Air Conditioning Compressor
- Energy Storage Systems (BESS) high-voltage wiring
- Rail transit and commercial electric vehicles
- High-voltage power distribution boxes and wiring harnesses
- Any application requiring waterproof, high-voltage, vibration-resistant 2-pin connections
