Remove Salty Underground 500L/H Brackish Water System
Price:
negotiation
MOQ:
>= 1sets
Delivery Time:
1-7working days(depand on raw materials stocking)
Brand:
Kaiyuan
Product Description
500L/H Brackish Water System Remove Salty Purification Filter For Underground Water
Change dirty water into pure water!!!
Product Description
Deal with raw water TDS range 5000 - 10000 ppm
Brackish water, according to the organic content can be devided into surface water and ground water . surface water we can reverse osmosis system mating with relative sterilization system , ground water we can direct use reverse osmosis system , if Iron and Manganese overpass the inlet condition of RO ,we need add Manganese sand filter for pretreatment system , here also include the specific inlet conditon of RO system for reference.
Product Details
| kyro-500lph RO Water Purifier Machine: |
| 1. Capacity: 5000L/H |
| 2. Rated power: 2.5KW/H |
| 3. Voltage: 110V/220V/380V, 50Hz/60Hz, single phase/3phase |
| 4. Desalting rate:>=97% |
| 5. Water recovery rate: 40% |
| 6. TDS of raw water: ≤20000μs |
| 7. TDS of pure water: ≤600μs |
A. Pretreatment system:
| (1) Raw water pump CHL2-30 SUS-316 |
| (2) Sand filter Φ250 × 1450 with 100KG sand / FRP tank |
| (3) Carbon filter Φ250 × 1450 with 25KG carbon / FRP tank |
| (4) Chemical dosing pump and tank |
| (5) Cartridge filter 20″×5μm 2core |
B. RO system parts:
| (1) High pressure pump: China Nanfang CNP brand |
| (2) Ro membrane: USA Dow brand |
| (3) RO membrane housing FRP |
|
(4) Ro rack and other related meters |
Product Processing
Raw water→ raw water pump→quartz sand filter →activated carbon filter→chemical dosing system→security filter→high pressure pump→ro system→water supply point
Some parts function for your reference as below^^:
Quartz sand filter: fill quarts sand inside, it can filter big particles impurities, suspended substances, colloids etc.
Activated carbon filter: fill activated carbon inside, to remove color, odor, residual chlorine and organics substances.
Security filter: fill PP filter cartridge inside, prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.
Chemical dosing system: add antiscalant(buyer supply), absorb Ca2+, Mg2+(main elements for composing scale), reduce hardness of raw water.
RO membrane: can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts.
UV sterilizer: for killing bacterial in water, be safe for drinking.
CIP system: its help to cleaning the RO membrane, so that it can be have long life span^^
Application
Feed water(source water):
city water, river water, lake water, underground water(borehole, well), brackish water, sea water......
Treated water:
1. Electronic industry: Pre-filter for ultra pure water, chemical products and pure water
2. Food and beverage industry: filter for mineral water, wines and fruit juice
3. Medicine industry: filter for drug liquid, gases
4. Chemical industry: filter for organic solvent
5. Petroleum industry: filter for oil-field flooding
Guidelines for getting a proper quotation:
1.Tell us the raw water/source of water
Provide water analysis report if possible
2.Required production capacity( 500 liters per hour, 1000liters per hour…)
3.What's the pure water used for( drinking, bottle water or industrial use…)
Any interested kust sent us inquiry please^^ whatsapp/wechat/tel: +86 13660858152
