63 Seats Diesel Engine Bus Double Back Axle Left Hand Drive 110km / H Max Speed
New Travelling Bus Daewoo 12m Length With 55Seats In Stock Left Hand Drive (LHD) Max.110KM/h Diesel Fuel
| Daewoo Bus GDW6121HK5 | |||||
| Parameters | |||||
| Dimensions (mm) | 12000*2550*3770 | G.V.W. (Kg) | 17250 | ||
| Wheelbase (mm) | 6300 | Curb WT (Kg) | 12960 | ||
| Seats | 53+2 (2X2 layout) | Max. grade ability (%) | ≥30 | ||
| Approach/departure angle (°) | ≥10.2/≥9.3 | Braking distance (m) | ≤36.7 | ||
| Ground clearance (mm) | ≥275 | Turning diameter (m) | 23 | ||
| Luggage capacity (m3) | 9.5 | Max. speed (km/h) | ≥120 | ||
| Fuel tank (L) | 320 | Fuel consumption (L/100km) | ≤23 (Rated condition) | ||
| Specifications | Optional | ||||
| Engine | Model | Yuchai, YC6L330-30, 330HP (E - III) | |||
| Output (kw/rpm) | 243/2200 | ||||
| Max. torque (N.m/rpm) | 1280/≤1400 | ||||
| Displacement (L) | 8.424 | ||||
| Chassis | Model | GL6120K | |||
| Clutch | Single plate with coil spring damper, D=φ430mm | ||||
| Gear box | 6-speed manual, 6S1550 | ||||
| Suspension | Multileaf spring | ||||
| Steering system | Power steering, RHD | ||||
| Braking system | Dual-circuit pneumatic braking,spring energy-storage parking brake,ABS,slack auto-adjuster,retarder | ||||
| Tire | 295/80R22.5 | ||||
| Body | Passenger door(front) | Aluminum alloy pneumatic out-swing,remote control | |||
| Middle door | Optional | ||||
| Luggage door | Tilt opening | ||||
| Side windows | close, tempered glass | open windows: +USD600 | |||
| Passenger seats | (2X2 layout only) Softening fabrics, high back adjustable, with movable armrests, first front row seats three-point seat belt, rest with two-point seat belt | with middle door: 51+2(2X2 layout) | |||
| Driver's seat | Omni-directional adjustable mechanical suspension damping |
||||
| Guide's seat | Folding seat | ||||
| A/C system | Ventilation system, Songz 28000kcal/h, Bitzer compressor | ||||
| Video & audio system | DVD + LCD | ||||
| USB PORT CHARGER | optional | USD200 | |||
| REVIEW MONITER | optional | USD200 | |||
| WIFI | optional | USD220 | |||
| Paint | DUPONT | ||||
| Others | Eelectric clock, Stainless hubcap, Sun visors | ||||
| Certificate | ISO9001:2008 | ||||
Trade Terms:
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.
