Anti-explosion slip ring with IP66 and optional for Low Temperature Environment
ECN000-EX-07P2-IP66 is CENO Anti-explosion Slip Ring with protection grade Exd II BT4 Gb IP66 and suit for low temperature environment from -40°C to +80°C. An explosion-proof slip ring is a conductive rotary connector specifically designed for flammable and explosive environments. Its core feature is to prevent electrical sparks from causing explosions while transmitting electrical signals, data, and current. For more information about how CENO slip ring can fit your application please contact us.
| ECN000-EX-07P2-IP66 | Specification |
|---|---|
|
Current & Circuits |
7 circuits * 10A |
|
Rating Voltage |
0 ~ 1000 VAC/VDC |
|
Dielectric strength |
≥1500VAC@50Hz |
|
Isolation resistance |
≥500MΩ@100VDC |
|
Contact resistance wave |
≤ 70mΩ |
|
Working temperature |
-40°C~+80°C |
|
Working humidity |
60 %RH |
|
IP protection grade |
IP66 |
|
Operating speed |
0~300rpm |
|
Outer diameter |
Ø180mm |
|
Contact material |
Precious Metal |
|
Housing material |
Aluminium Alloy |
|
Explosion-proof grade |
Exd II BT4 Gb IP66 |
|
Lead wire size & length |
Customized |
Features
u Safe explosion-proof design, such as sealed explosion-proof construction
u using a high-strength casing, and precisely machined mating surfaces
u IP Grade be up to 67 and optional
Applications
u Rotating reactors
u Rotating platform
u Construction machinery
u Energy equipment
u Fuel refueling systems
Optional
u Circuit, Voltage, Current
u Signals and data
u Contact / Housing Materials
u Anti-explosion grade
u Working speed & temperature
