API Certified Steel Casing Pipe Oilfield Drill Pipe PSL1 PSL2 PSL3 Class
Price:
Negotiable
MOQ:
1 metric ton
Delivery Time:
Negotiable
Brand:
Zhongshi
Product Description
API Certified PSL1 PSL2 PSL3 Class Oilfiled Tubing Pipe Used In Oil Production
Description of tubing:
Tubing is pipe used for the transportation of crude oil and natural gas from an oil or gas layer
to the surface after drilling is complete. It is made to withstand the pressure generated from
the extraction process.
Features:
1.Specification range:OD: 42.16 MM - 114.3 MM(1.66"--4 1/2") WT:3.56-16mm(2.3ppf-26.1ppf)
2. Materials: H40, J55, K55, N80-1, N80-Q, L80-1,L80-9Cr, L80-13Cr, P110, Q125 etc
3. Executive standards: API 5CT, GB, ISO11960, GOST
4. Thread connection: NU, EU,IJ
5. Length: R1, R2, R3
6. Testing: NDT etc related rules of API 5CT and 5B
7:Type:seamless pipe
Technical specification:
| Spec. | O.D. | Nominal weight | Wall thickness | Upset type | ||||||||||||
| NU with thread and coupling | EU with thread and coupling | |||||||||||||||
| In | Mm | In | Kg/m | Lb/ft | Kg/m | Lb/ft | Mm | In | H40 | J55 | L80 | N801,Q | C90 | T95 | P110 | |
| 1.05 | 26.67 | 1.05 | 1.7 | 1.14 | 1.79 | 1.2 | 2.87 | 0.113 | NU | NU | NU | NU | NU | NU | - | |
| 1.05 | 26.67 | 1.05 | 2.2 | 1.48 | 2.29 | 1.54 | 3.91 | 0.154 | U | U | U | U | U | U | U | |
| 1.315 | 33.4 | 1.315 | 2.53 | 1.7 | 2.68 | 1.8 | 3.38 | 0.133 | NU | NU | NU | NU | NU | NU | - | |
| 1.315 | 33.4 | 1.315 | 3.26 | 2.19 | 3.33 | 2.24 | 4.55 | 0.179 | U | U | U | U | U | U | U | |
| 1.66 | 42.16 | 1.66 | 3.42 | 2.3 | 3.57 | 2.4 | 3.56 | 0.14 | NU | NU | NU | NU | NU | NU | - | |
| 1.66 | 42.16 | 1.66 | 4.51 | 3.03 | 4.57 | 3.07 | 4.85 | 0.191 | U | U | U | U | U | U | U | |
| 1.9 | 48.26 | 1.9 | 4.09 | 2.75 | 4.32 | 2.9 | 3.68 | 0.145 | NU | NU | NU | NU | NU | NU | - | |
| 1.9 | 48.26 | 1.9 | 5.43 | 3.65 | 5.55 | 3.73 | 5.08 | 0.2 | U | U | U | U | U | U | U | |
| 2 3/8 | 60.32 | 2.375 | 5.95 | 4 | - | - | 4.24 | 0.167 | U | N | N | N | N | N | - | |
| 2 3/8 | 60.32 | 2.375 | 6.85 | 4.6 | 6.99 | 4.7 | 4.83 | 0.19 | NU | NU | NU | NU | NU | NU | NU | |
| 2 3/8 | 60.32 | 2.375 | 8.63 | 5.8 | 8.85 | 5.95 | 6.45 | 0.254 | - | - | NU | NU | NU | NU | NU | |
| 2 3/8 | 60.32 | 2.375 | 10.94 | 7.35 | 11.09 | 7.45 | 8.53 | 0.336 | - | - | U | - | U | U | - | |
| 2 7/8 | 73.02 | 2.875 | 9.52 | 6.4 | 9.67 | 6.5 | 5.51 | 0.127 | NU | NU | NU | NU | NU | NU | NU | |
| 2 7/8 | 73.02 | 2.875 | 11.61 | 7.8 | 11.76 | 7.9 | 7.01 | 0.276 | - | - | NU | NU | NU | NU | NU | |
| 2 7/8 | 73.02 | 2.875 | 12.8 | 8.6 | 12.95 | 8.7 | 7.82 | 0.308 | - | - | NU | NU | NU | NU | NU | |
| 2 7/8 | 73.02 | 2.875 | 13.91 | 9.35 | 14.06 | 9.45 | 8.64 | 0.34 | - | - | U | - | U | U | - | |
| 3 1/2 | 88.9 | 3.5 | 11.46 | 7.7 | - | - | 5.49 | 0.216 | N | N | N | N | N | N | - | |
| 3 1/2 | 88.9 | 3.5 | 13.69 | 9.2 | 13.84 | 9.3 | 6.45 | 0.254 | NU | NU | NU | NU | NU | NU | NU | |
| 3 1/2 | 88.9 | 3.5 | 15.18 | 10.2 | - | - | 7.34 | 0.289 | N | N | NU | N | N | N | - | |
| 3 1/2 | 88.9 | 3.5 | 18.9 | 12.7 | 19.27 | 12.95 | 9.52 | 0.375 | - | - | NU | NU | NU | NU | NU | |
| 4 | 101.6 | 4 | 14.14 | 9.5 | - | - | 5.74 | 0.226 | N | N | N | N | N | N | - | |
| 4 | 101.6 | 4 | - | - | 16.37 | 11 | 6.65 | 0.262 | U | U | U | U | U | U | - | |
| 4 1/2 | 114.3 | 4.5 | 18.75 | 12.6 | 18.97 | 12.75 | 6.88 | 0.271 | NU | NU | NU | NU | NU | NU | - | |
