Rotary Die Cutter Stacker 12kw Automatic Corrugation Machine

Price Negotiable

Price: negotiation

MOQ: 1set

Delivery Time: 25days after deopist

Brand: SOOME

Product Description

Printing roller

1. Outer diameter: Ø408.4(incl. edition),seamless steel pipe, with surface grinding, hard chrome plating.

2. Printing roller made of high quality steel, with surface grinding and hard chrome plating.

3. Dynamic balancing correction, stable operation.

4. Ratchet wheel fixed rolled shaft.

5. Install & uninstall printing edition controlled by electric.

Printing pressing roller

1. Outer diameter: Ø176mm,seamless steel pipe, with surface grinding, hard chrome plating.

2. Dynamic balancing correction, stable operation.

3. Automatic locking on adjustment of pressing roller space, adjust scope is 0-11mm.

4. Automatic return to zero device, decrease the paper waste.

Anilox roller : Ø216mm(as per customer required

1. With surface grinding on the steel pipe,pressing checkered, chrome plating.

2. Dynamic balancing correction, stable operation.

3. Cooperated with pneumatic lifting device.

4. Matched with surpass clutch, distribute and clean the ink more easily.

5. Optional: Ceramic anilox roller equipped with ink scraper, make the printing effect better.

Rubber roller

1. Outer diameter: Ø208mm.

2. Wrapped with wear-resisting rubber on the steel pipe surface.

3. Rubber roller with special grinding to reach good effect of ink transmission.

Adopt automatic locking for the space adjustment between rubber rollers.

Single shaft with dual cutter. Electric adjust the carton height with high precision.

1. Creaser and pre-creaser Ø180mm,above crease wrapped with optimal rubber will not damage the paper.

2. Creaser, pre-creaser, diecutting cutter holder move together by NC controller.

3. Spacing adjustment of creaser and pre-creaser adopt self-locking mechanism, scope is 0-11mm.

Rubber mat roller

1. Equipped with rubber mat holder Ø404*5pcs.

2. Axial direction auto circulation translation.

3. Equipped with linear compensation device, with average diecutting of rubber mat.

4. With pneumatic lifting device, protect the rubber mat.

5. International famous Maxdura anvil blanket.

Techincal index:

SMYS-QY-2600	Unit	SMYS-QY-2600
Plate roller diameter	mm	408
Plate roller length	mm	2500
Inner width of machine	mm	2600
Speed	pcs/min	120
Max printing area	mm	1200×2200
Max feeding paper size	mm	1200×2400
Feeding paper by skip	mm	1400x2400
Min feeding paper size	mm	350×720
Board thickness	mm	2-11
Print plate thickness	mm	7.2
Print roller axle circle-oriented regulating	degree	360°revolving
Topping precision	mm	360°revolving
