Semi-Automatic Corrugated Cardboard Carton Stitcher Machine

Functional features:

Japan's Anchuan/Mitsubishi original imported double servo drive, accurate accuracy, mechanical transmission part reduction, can effectively reduce the mechanical failure rate

Taiwan Weinview touch screen operation, parameters (nail distance, number of nails, nail type, back panel) change quickly and easily

The rear electric baffle is driven by stepper motor, the size is accurate, and the size is more convenient and quick

The whole set of nail heads are all made of original Taiwanese parts, and the machine head has a longer service life

Can be nailed single nail, double nail, and reinforced nail (two ends are double nails in the middle part), which can be done in one time, which can meet different requirements of different customers

Change the size of the carton and adjust the carton nail distance in one minute, saving time and easy operation

Two-way front and rear baffle, can be nailed with a cover box, no cover carton

The front feed unit automatically counts, and the paper feed table is equipped with a photoelectric sensor that automatically rises when feeding

There is an automatic counting function in the back section. The number of finished products that can be prepared can be sent to the end of the conveying machine in a set number (2-99), which is convenient for packing and bundling

Electric adjustment of paper pad rubber wheel gap

Order adjustment of the whole machine, can store 1000 orders

The whole machine isolating transformer protection device to better protect the service life of the whole computer hardware

Automatic wire feeding system without wire alarm, 20KG large flat wire, saving time

Techincal index:
