Electric Adjustment Automatic Paperboard Slitting Creasing Machine

1. Summarize

Automatic paperboard slitting creasing machine with full-electric adjustment for blades and creasers, adopting two shafts in front and back of the slitter, can minimize the length of paperboard machining. Not only meet the conventional cutting board size, could be also used for cutting small paperboard pallets and other specifications. Electric-control adjusts thin blades and scorer movement is adjusted by electric.

2. Features and Functions

1).Slitting part: Automatic paperboard slitting creasing machine adopt high quality tungsten steel alloy thin blade, sharp and long service life, slice more tidy, non-pressing and non-burr.
2).Grinding part: Automatic paperboard slitting creasing machine adopt automatic and manual two kinds pneumatic grinding type. It can be grinding when working, improved the work efficiency.
3).Scoring part: Automatic paperboard slitting creasing machine adopt 5 points scoring, scoring distance adjusted synchronously, blazonry and easy to bend the carton sheet.
4).Automatic paperboard slitting creasing machine adopt China famous brand or imported electric elements, reliable performance.
5).Electric left-right rectification 200mm function to cooperate the position of paper sheet.
6).The space between slitting blades is electrically adjusted, automatic locking, can reach min. slitting width 130mm.
7).Double smooth shaft guide way, stable operation; inlay O-ring seal, clean and dust-proof.
8).Self-researched nut rotation technique with the automatic locking function, simple and useful.

3. Technical Parameters
