2000 Type Thin Blade Slitter Scorer For Corrugated Cardboard Production Line

Product overview:

  As an important equipment of corrugated cadres,complete the high quality line of cardboard and precise cutting and the size is very precise.Adopt computer-controlled,automatic change order,and reduce waste,improve work efficiency.

Function and Characteristic:

1 . High quality touch screen and PLC equipped composing the CNC system,connect to the production line.

2 . High quality beeline rail guarantees the precision.

3 . A memory of orders,realize non-stop automatic or manual change.

4 . Speed synchronizes with board speed.Standard communication interface,easy to link with management system.

5 . Alloyed steel thin-blades,sharp and long life of over 8 million meters,auto sharpening

6 . The knife for computer control automatic or manual knife sharpening,edge trimming knife,improve production efficiency.

7 . Two types of scorers:convex to concave ,convex to flat.

8 . Two rows of scorers,realizes minimum scorer spacing is 0mm.

9 . Computer control score-depth,high quality scorer,more steady .

10 . Using the synchronous belt transmission ,low noise,prolong using time.

11 . Standard motorized body left-right rectification system 200mm

Technical Specifications:
