1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet
1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet
Automatic unmanned baler according to the latest development of electronic logic circuit system, can improve the speed and accuracy of the machine. The machine can achieve unattended baling, also can control the whole baling process by single key, simple and easy to use. According to customer requirements, 1-2 bales can be set. Unmanned baler selection of international famous brand electrical components, the whole machine quality is stable and reliable. Packing position: the position of electric eye can be adjusted as required. Unmanned baler can be used alone or with conveyor design automation and unmanned baling system, to meet the needs of customers.
Technical parameters
| Model | 1250 |
| Size | L1580*W600*H1900 |
| Table Height | 850mm |
| Machine weight | 365Kg |
| Strapping speed | >=55pcs/min |
| Strapping specifications | Min.packing size W80mm*H60mm,Max.frame size |
| Power | 600W.10A |
| Working environment | Relative humidity≦90%,temperature 0-40℃, noise≦75dB(A) |
| Belt width/Belt thickness | 5mm-9mm 0.5-0.6mm |
| Belt index dial specification | Paper core inner diameter 200mm-210mm,outer diameter 400-450mm,width 175-190mm |
| Glue way | Heat fusion |
| Glue connect way | Bottom glue, glue area ≧90%,glue location deviation≦2mm |
| Tightness degree | 0-45KG |
| Air pressure | 0.4-0.6MPa |
| Max.strapping size | L*W1200*H420 |
