Automatic 2500 Length 480 Corrugated Cardboard Corner Cutter Machine

  This machine for corrugated corner cutting.The incision is neat, no burr, the computer control can choose a variety of boxes. Change orders quickly, save labor. Precise size, stable operation.

1 . Power motor 2.2KW, gear reducer, frequency converter governing speed

2 . The machine weight is 1700KG

3 . Machine power: 4.2kW

4 . Transmission synchronous belt 8m-1400X60

5 . The low-voltage electrical appliances adopt schneider Delta and other brands

6 . The inverter adopts delta brand

7 . 5 sets of 400W servo motors and servomotors adopt the domestic Brand of Aorui

8 . The touch screen is under the Kunlun Tongtai brand

9 . PLC USES delta brand

10 . The sensor USES the Befuning brand

11 . Use the helical rack drive to make the positioning error in addition or subtraction 0.5mm
12 . The exterior dimension is 3400mm long, 1400mm wide and 1600mm high

Parameter
