Industrial Vacuum Packing Machine Fruit Vacuum Tray Sealer Packaging Machine
Industrial Vacuum Packing Machine Fruit Vacuum Tray Sealer Packaging Machine
Modified atmosphere packing machine system solution supplier:
RODBOL was established in Chengdu, China in 2015. Our company is one of the earliest professional manufacturers of modified atmosphere packaging machine and in the lead in terms of structure, technology and quality of MAP.
In 2018, our company developed a vacuum skin packaging machine to make the packaged products more three-dimensional.he vacuum skin packing wraps product gently like its second skin.It shows the best quality of product, and ,makes it easy to choose.
RODBOL dedicated to researching, promoting, developing, improving, innovating, disseminating and providing services in the area of packaging technologies.
RODBOL can offer customers a extensive range of machines from a simple table top sealer to complete, fully automatic high speed lines, including Automatic drop tray, conveying, tray filling, film sealing, metal detection, Weighing and labeling. Applications include ordinary sealed packaging and modified atmosphere packaging (MAP)
RDW 500P automatic horizontal atmosphere modified fresh-keeping packaging machine is suitable for medium and large supermarkets and food processing plants. Applications include fresh meat, fruits and vegetables and cooked food. The packaging speed is fast and the stability is strong. The king of value for money. The unique inheritance and parallel mechanism makes the assembly line simpler and more efficient. Imported high-precision replacement technology, the residual oxygen rate of each box is less than 0.5%. Oversized molds to complete more packaging at once. The high-precision chain feeding method is accurate and stable.
Specification:
| Product name | MAP Tray Sealing Machine Customize Fruit Vacuum Tray Sealer Packing Machine |
| Product type | RDW500P |
| Machine weight | 750kg |
| Power supply | 220/50 V/Hz or customize |
| Working pressure | 0.6-0.8 MPa |
| Type | AUTOMATIC / Horizontal |
| Main structure material | 304 Stainless steel,Aluminum alloy |
| Max. Tray dimensions | 450×300×85mm |
| Max. Film width | 540mm |
| Max. Film diameter | 260mm |
| Power | 3.2kw |
| Air Exchanging Rate | ≥99% |
| Gas mixture precision | ±1% |
| Machine dimensions | (L) 3230 ×(W) 940×(H) 1800mm |
| Capacity | 1300-1500pcs/h |
|
Gas |
CO2, N2 and O2 |
External factors affecting the shelf life of modified atmosphere fresh-keeping packaging products:
| 1 | Temperature control: including ambient temperature control for processing, packaging, storage, transportation, and sales. |
| 2 | Hygienic management: product processing and packaging adhere to good hygienic management (GMP) and implement HACCP management system. |
| 3 | Quality of raw materials: initial bacterial count and physical and chemical indicators such as peroxide value (PV), thiobarbituric acid value. |
| 4 | Other ingredients in the final product. |
| 5 | Time interval from processing to packaging. |
| 6 | Gas to product volume ratio. |
| 7 | Mixed gas ratio accuracy and residual gas composition (% residual oxygen). |
| 8 | O2, CO2, N2 permeability of packaging materials. |
Payment
30% deposit before production, balance before shipment.
Shipping:
1. Air freight shipment-- via DHL,UPS,FEDEX,EMS etc (we will professionally choose the best way to save money for different areas);
2. Sea freight ( you can choose your ideal agent to deal or we can handle it for you without any of ur concern);
3. You can pick up at our warehouse.
