45Hz Rectifier Modules NPR48 220V 48V 50A DC Communication Power
45Hz Rectifier Modules NPR48 220V 48V 50A DC Communication Power
Overviews
The Eaton NPR48 Series of rectifier modules is designed for a wide range of telecommunications applications including
switching, wireless, and transmission.
flexible, efficient, and reliable DC power source. It is designed for operation at up to 70°C (158°F) and under a wide range of AC power conditions.
The NPR48 Series rectifiers are up to 92% efficient with optimum performance available at typical load currents. These
rectifiers also offer two output modes; either constant power or constant current.
* Fast on-line replacement of rectifiers (hot-swap)
* Automatic set-up from supervisory module
* Intelligent microprocessor controlled
* High power density
* High efficiency and unity power factor
* Wide AC supply conditions
* Wide output voltage range
* Constant power or constant current output modes
* Compliance with international standards
Specifications
| AC input | Input voltage range: 90V～300V (single-phase three-wire) Input frequency range: 45Hz～55Hz Power factor: >0.99 (50～***RRC) |
| DC output | Output voltage range: 43V～57.6V continuously adjustable Efficiency: >90% Stabilization accuracy: <±0.5% System Configuration |
| AC input | three-phase five-wire system, input voltage range 90～300V |
| Protection function | with incoming line overload and short circuit protection functions. Single * control the power distribution of each rectifier, provide rectifier overload and short circuit * dual protection. AC input has C-level lightning protection and alarm functions |
| DC output |
■ MCB: 16 channels: 63A～100A 24 channels: 1A～63A ■ Fuse: 10 way: NH00, 2A～160A 6 way: NH01, 2**～250A ■ Battery branch: 500A and below *2, optional for secondary power-off ■ System capacity: 48V/300A, 48V/600A, 24V/900A, 48V/900A ■ Configurable rectifier modules: APR48-3G-48V/1800W, APR48-ES-48V/2000W (*** module), NPR48-3G-48V/2900W, APR24-3G-24V/1440W ■ Configurable monitoring module: SM45 (SC100) ■ Wiring mode: up and down line in and out or choose according to user requirements |
FAQ
Q: How is the quality?
A: 100% original new packaging. We will test each product before launch to ensure that each product is of good quality.
Q: How many months is the warranty?
A: 12 months warranty
Q: How to deal with any low-quality goods?
A: During the warranty period, any products of poor quality can be mailed, and we will charge a mailing fee.
Package
1. Original carton or Mood box packaging.
2. According to customer requirements.
Deliver goods
1. 3-7 working days after receipt of payment.
2. Shipment: sea and air (DHL / UPS / TNT / Fedex / EMS)
